About SINAMICS V20 6SL3210-5BE13-7CV0

SINAMICS V20 380-480 V 3 AC -15/+10% 47-63Hz rated power 0.37 kW with 150% overload for 60 sec. Integrated filter C3 I/O: 4 DI, 2 DO,2 AI, 1 AQ fieldbus: USS/MODBUS RTU with built-in BOP protection: IP20/ UL open size: A 90x150x146 (WxHxD)

SINAMICS V20

• Article No.: 6SL3210-5BE13-7CV0
• Type: Compact AC Drive
• Phases: 3 AC
• Cooling: Convection cooling (IP20 / UL open type)
• Mounting: Wall mounting / side-by-side
• Frame Size: FSA
• Net Weight: 1.00 kg

Input Data

• Line Voltage: 380480 V (-15% / +10%)

• Line Frequency: 4763 Hz

Output Data

• Phases: 3 AC

• Rated Voltage: 400 V IEC / 480 V NEC

• Rated Power: 0.37 kW / 0.50 hp (LO & HO)

• Rated Current: 1.30 A (LO, HO, IN)

• Pulse Frequency: 4 kHz

• Output Frequency: 0550 Hz

Overload Capability

General Technical Data

• Power Factor (): 0.72

• Offset Factor (cos ): 0.95

• Efficiency (): 0.98

• Filter Class: Class A

Communication

• Protocols: USS, Modbus RTU

Inputs / Outputs

• Digital Inputs: 4

• Digital Outputs: 1 relay changeover contact, 1 transistor

• Analog Inputs: 2 (can be used as digital)

• Analog Outputs: 1

Ambient Conditions

• Operation Temperature: -10 60 C (derating above 40 C)

• Storage Temperature: -40 70 C

• Max Relative Humidity: 95%

• Installation Altitude: 1,000 m

Connections

• Max Motor Cable Length:

  • Shielded: 10 m

  • Unshielded: 50 m

Mechanical Data

• Dimensions (W H D): 90 150 145.5 mm
