About SINAMICS V20 6SL3210-5BE24-0UV0

The SINAMICS V20 6SL3210-5BE24-0UV0 is a versatile drive with the rated voltage of 380-480 Volt, making it ideal for industrial applications. It features V/F control for precise performance, a digital display for easy monitoring, and a compact size of 140x160x164.5 mm. With an IP20 protection level, it ensures safety in various operating environments. This drive comes with a 1-year warranty, providing reliability and peace of mind. Operating at a frequency range of 47-63 Hz, it offers a wide spectrum of usability for different industrial settings.

Data Sheet SINAMICS V20

Article No.: 6SL3210-5BE24-0UV0
Technical data are subject to change. There may be discrepancies between calculated and rating plate values.

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380 ... 480 V (-15% / +10%)

• Line frequency: 47 ... 63 Hz

Output

• Number of phases: 3 AC

• Rated voltage: 400V IEC / 480V NEC

• Rated power (LO): 4.00 kW / 5.00 hp

• Rated power (HO): 4.00 kW / 5.00 hp

• Rated current (LO): 8.80 A / 8.20 A

• Rated current (HO): 8.80 A / 8.20 A

• Rated current (IN): 8.80 A

• Pulse frequency: 4.00 kHz

• Output frequency: 0 ... 550 Hz

Overload Capability

• Low Overload (LO): 110% rated output current for 60 s, cycle time 300 s

• High Overload (HO): 150% rated output current for 60 s, cycle time 300 s

General Technical Specifications

• Power factor : 0.72

• Offset factor cos : 0.95

• Efficiency : 0.98

• Filter class (integrated): Unfiltered

Communication

• USS, Modbus RTU

Inputs / Outputs

Standard Digital Inputs

• Number: 4

Digital Outputs

• Relay changeover contact: 1

• Transistor: 1

Analog Inputs

• Number: 2 (Can be used as additional digital input)

Analog Outputs

• Number: 1

Ambient Conditions

• Cooling: External fan

• Installation altitude: 1,000 m

• Ambient temperature (operation): -10 ... 60 C

• Storage temperature: -40 ... 70 C

• Max. relative humidity: 95%

Connections

Max. Motor Cable Length

• Shielded: 25 m

• Unshielded: 50 m

Mechanical Data

• Mounting: Through-hole / wall mounting / side-by-side

• Degree of protection: IP20 / UL open type

• Frame size: FSB

• Net weight: 1.60 kg

• Dimensions:

  • Width: 140.0 mm

  • Height: 160.0 mm

  • Depth: 164.5 mm
