SIEMENS ET 200SP, AQ 2 X UI High Feature 6ES7135-6HB00-0CA1

The Siemens ET 200SP AQ 2 x UI High Feature 6ES7135-6HB00-0CA1 is a compact and reliable automation module designed for seamless integration into industrial environments. With a rated voltage of 24V DC and an input current of 90 mA, it delivers precise and consistent performance. The module boasts space-saving dimensions of 15 x 73 x 58 mm and weighs only 31 grams, making it ideal for installations with limited space. It features DIN-rail mounting for easy setup and complies with IP20 protection standards, ensuring safe operation in demanding conditions. Engineered to withstand operating temperatures from -30C to +60C and humidity levels up to 95%, this module is highly durable and suitable for challenging environments. Additionally, it offers reliable isolation up to 707V DC and a power loss of only 0.9W, promoting energy efficiency. Designed for 50/60 Hz systems, the Siemens ET 200SP module is perfect for advanced industrial automation applications.

General Information

• Product Type: AQ 2x U/I HF

• HW Functional Status: From FS21

• Firmware Version: V1.0.3

• FW Update Possible: Yes

• Supported BaseUnits: BU Type A0, A1

• Color Code: CC00

Product Functions

• I&M Data: Yes (I&M0 to I&M3)

• Isochronous Mode: Yes

Engineering Compatibility

• STEP 7 TIA Portal: From V13

• STEP 7: From V5.5 SP3

• PCS 7: From V8.1 SP1

• PROFIBUS (GSD): Revision 5

• PROFINET (GSDML): V2.3

Operating Mode

• Oversampling: No

• MSO: No

CiR (Configuration in RUN)

• Reparameterization in RUN: No

• Calibration in RUN: No

Supply Voltage

• Rated Value: 24 V DC

• Range: 19.228.8 V

• Reverse Polarity Protection: Yes

Input Current

• Rated Consumption: 45 mA (without load)

• Max Consumption: 90 mA (2 current output at 20 mA)

Power Loss

• Typical Power Loss: 0.9 W

Address Area

• Address Space per Module: 4 bytes + 1 byte QI

Hardware Configuration

• Automatic Encoding: Yes

• Mechanical Coding: Yes (Type A)

Analog Outputs

• Number of Outputs: 2

• Short-Circuit Protection (Voltage Output): Yes

• Max Short-Circuit Current: 45 mA

• Min Cycle Time (all channels): 750 s

Voltage Output Ranges

• 010 V: 15-bit

• 15 V: 13-bit

• 5 to +5 V: 15-bit

• 10 to +10 V: 16-bit

Current Output Ranges

• 020 mA: 15-bit

• 20 to +20 mA: 16-bit

• 420 mA: 14-bit

Load Impedance

• Voltage Output (min): 2 k

• Capacitive Load (max): 1 F

• Current Output (max): 500

• Inductive Load (max): 1 mH

Cable Length

• Shielded: up to 1000 m

• Voltage Outputs: up to 200 m

Analog Value Generation

• Resolution (max): 16-bit including sign

• Settling Time:

  • Resistive Load: 0.05 ms

  • Capacitive Load: 0.05 ms (Max 47 nF, 20 m cable)

  • Inductive Load: 0.05 ms

Errors / Accuracy

• Output Ripple: 0.02%

• Linearity Error: 0.03%

• Temperature Error: 0.003%/K

• Crosstalk: -50 dB

• Repeat Accuracy: 0.03%

Operational Error Limit:

• Voltage: 0.2%

• Current: 0.2%

Basic Error (at 25C):

• Voltage: 0.1%

• Current: 0.1%

Isochronous Mode

• Execution & Activation Time: 500 s

• Bus Cycle Time: 750 s

• Jitter (max): 5 s

Diagnostics

• Diagnostics Function: Yes

• Substitute Values: Yes

• Diagnostic Alarms: Yes

Diagnostic Types:

• Supply Voltage Monitoring

• Wire Break (current outputs)

• Short Circuit (voltage outputs)

• Group Error

• Overflow / Underflow

LED Indicators:

• PWR LED: Green

• Channel Status: Green

• Channel Diagnostics: Red

• Module Diagnostics: Green/Red

Isolation / Potential Separation

• Between Channels: No

• Channels Backplane Bus: Yes

• Channels Electronics Supply: Yes

• Isolation Test Voltage: 707 V DC

Environmental Conditions

• Operating Temperature (Horizontal): -30C to +60C

• Operating Temperature (Vertical): -30C to +50C

• Max Installation Altitude: 5000 m

Physical Specifications

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 31 g
