SIEMENS ET 200SP, F DI 8x24V DC HF 6ES7136 6BA01 0CA0

The ET 200SP, F DI 8x24V DC HF 6ES7136 6BA01 0CA0 is a high-quality industrial automation module designed for a rack mount setup. With a frequency of 50/60 Hertz (HZ), this yellow-colored module ensures efficient operation in a standard size configuration. It is ideal for exporters, manufacturers, suppliers, and traders looking for reliable industrial automation solutions.

Siemens SIMATIC ET 200SP F-AI 4xU 010V HF (Fail-Safe Analog Input Module)

Part Number: 6ES7136-6AB00-0CA1

General Information:

• Module Type: F-AI 4xU 010V HF, fail-safe

• Firmware: Update possible

• Usable Base Units: BU type A0, A1

• Color Code: CC00

• Product Function: I&M data (I&M0 to I&M3)

• Engineering: STEP 7 TIA Portal V16 or higher

• Operating Mode: Cyclic measurement (oversampling: No)

• CiR (Configuration in RUN): Not supported

Supply Voltage & Power:

• Rated voltage: 24 V DC (range: 19.228.8 V DC)

• Reverse polarity protection: Yes

• Current consumption: 0.38 A (typ), max 0.4 A

• Power consumption from backplane bus: 70 mW

• Power loss: 2 W

Encoder Supply:

• 24 V output, short-circuit protected

• Max output current: 300 mA (total for all encoders/channels)

Address Area:

• Inputs: 14 byte (S7-300/400F: 13 byte)

• Outputs: 5 byte (S7-300/400F: 4 byte)

Analog Inputs:

• Number of inputs: 4 (voltage measurement)

• Rated input range: 010 V

• Input resistance: 16 k

• Max permissible input voltage: 36 V

• Max cable length: 200 m (shielded)

• Measurement principle: Sigma-Delta

• Resolution: 16 bit (including sign)

• Integration time: 20 ms / 16.667 ms (parameterizable)

• Interference suppression: 50/60 Hz

Smoothing & Filtering:

• 7 smoothing levels (None, Low, Medium, High)

• Average value filter: Yes

Accuracy & Errors:

• Linearity error: 0.1 %

• Temperature error: 0.023 %/K

• Repeat accuracy: 0.1 %

• Operational error (overall temp range): 2 %

• Basic error limit: 0.1 %

• Common-mode interference: min. 70 dB, max. 10 V

• Series-mode interference: min. 40 dB

Diagnostics & Status:

• Diagnostics function: Yes

• Diagnostic alarm: Yes

• Monitoring supply voltage: Yes

• Wire-break detection: Yes

• LEDs:

  • RUN (green)

  • ERROR (red)

  • PWR (green)

  • Channel status (green/red)

  • Module diagnostics (green/red DIAG)

Potential Separation & Isolation:

• Between channels: No

• Between channels & backplane bus: Yes

• Between channels & electronics supply: Yes

• Permissible potential difference between inputs (UCM): 10 Vpp

• Isolation tested: 707 V DC

Safety & Functional Safety:

• Performance level: PL e (ISO 13849-1)

• Category: Cat. 4

• SIL: SIL 3 (IEC 61508)

• Probability of failure (20-year service life, 100h repair):

  • Low demand: PFDavg < 5.00E-05

  • High demand/continuous: PFH < 1.00E-09 1/h

Ambient Conditions:

• Operation: 060 C (horizontal), 050 C (vertical)

• Dimensions: W 15 mm H 73 mm D 58 mm

• Weight: 48 g
