About SIEMENS POWER SUPPLY 6EP4347-7RB00-0AX0

The Siemens Power Supply 6EP4347-7RB00-0AX0 is a new industrial-grade power supply designed to provide reliable and efficient power to your industrial equipment. With a voltage output of 24V, this standard-sized power supply is suitable for a variety of industrial applications. The grey-colored power supply operates in electric power mode and comes with a warranty of 1 year, ensuring peace of mind and product reliability.

SITOP RED1200 Redundancy Module

Part Number: 6EP4347-7RB00-0AX0
Type: Redundancy Module
Function: Decouples two SITOP power supplies (max. 20 A each)

Input

• Type of power supply: DC voltage

• Supply voltage range: 12 48 V DC

• Input voltage range: 10 58 V DC

Output

• Number of outputs: 1

• Output voltage (rated): 24 V DC

• Output voltage formula: Vin - approx. 0.6 V

• Output voltage adjustable: No

• Output current (rated): 40 A

• Bridging of equipment: No

Efficiency & Power Loss

• Efficiency: 97.5 %

• Power loss at rated output: 25 W

• Power loss at no-load: max. 0.1 W

Safety

• Galvanic isolation: No

• Protection class: Class III

• Enclosure protection: IP20

EMC Standards

• Emitted interference: EN 61000-6-3

• Interference immunity: EN 61000-6-2

Certifications / Approvals

• CE marking: Yes

• UL: cULus-Listed (UL 508, CSA C22.2 No. 107.1)

• CSA: C22.2 No. 62368-1

• NEC Class 2: No

• MTBF @ 40 C: 6,100,000 h

Hazardous Environment Approvals

• IECEx, ATEX, UL Hazloc, cCSAus Class 1 Division 2, FM: No

Marine Classification

• ABS, BV, DNV, LRS: No

Environmental Product Declaration

• Total CO eq: 805.5 kg

• Manufacturing: 51.1 kg

• Operation: 1,051.5 kg

• End of life: 0.81 kg

Ambient Conditions

• Operating temperature: -40 +70 C (natural convection)

• Storage/transport temperature: -40 +85 C

• Environmental category: IEC 60721, Climate class 3K3, 5 95% RH, no condensation

Connection Method

• Type: Push-in terminals

• Input terminals (In1, In2): 0.75 16 mm

• Output terminal (Out1): 0.75 16 mm

Mechanical Data

• Dimensions (WHD): 45 135 125 mm

• Installation width mounting height: 45 mm 225 mm

• Required spacing: Top 45 mm / Bottom 45 mm / Left 0 mm / Right 0 mm

• Mounting: DIN rail EN 60715 357.5/15

• Wall/S7 rail mounting: No

• Housing: Can be lined up

• Net weight: 0.51 kg
