SIEMENS ET 200SP, RQ CO 3x120VDC.230VAC5A ST 6ES7132-6HC50-0BU0

The SIEMENS ET 200SP RQ CO 3x120VDC.230VAC5A ST (Model: 6ES7132-6HC50-0BU0) is a high-performance distributed I/O system designed for advanced automation applications. It supports a rated voltage of 24V DC and offers an output voltage of 230V, making it ideal for industrial environments. With a rated current of 55 mA, robust isolation at 2000V DC, and power loss restricted to 1.6W, it ensures reliable functionality. Compact and lightweight, it measures 20 x 73 x 58 mm and weighs just 40 grams, facilitating easy DIN-rail mounting even in tight spaces. This unit is built to withstand harsh conditions with an operating temperature range of -30C to +60C and humidity tolerance up to 95%. The IP20 protection level ensures secure operation while safeguarding against solid particle intrusion. Its versatility is further bolstered with compatibility for frequencies of 50/60 Hz, underscoring its suitability for cutting-edge automation systems.

SIMATIC ET 200SP Relay Module RQ 3x120VDC-230VAC/5A CO ST (6ES7132-6HC50-0BU0)

General Information

• Product Type: RQ 3x120VDC-230VAC/5A CO ST

• Firmware Version: V0.0 (FW update not possible)

• Base Unit: BU type U0

• Color Code: CC20

• I&M Data: Yes (I&M0 to I&M3)

• Engineering: Configurable via STEP 7 TIA Portal V16+, GSD/GSDML files

Supply Voltage

• Rated Value: 24 V DC

• Permissible Range: 19.2 28.8 V DC

• Reverse Polarity Protection: Yes

• Current Consumption: 40 mA (typical, no load), 55 mA (max)

Digital Outputs

• Output Type: Relays (3 CO, isolated)

• Current-Sinking / Sourcing: Yes

• Parameterizable: Yes

• Short-Circuit Protection: No

• Switching Capacity:

  • Resistive Load: Max 5 A

  • Inductive Load: Max 2 A

  • Lamp Load: Max 2 Hz

• Switching Frequency:

  • Resistive: 2 Hz

  • Inductive: 0.5 Hz

  • Lamp: 2 Hz

• Total Current:

  • Per Channel: 5 A

  • Per Module: 15 A (horizontal/vertical installation limits apply)

Relay Outputs

• Number of Relay Outputs: 3 (changeover contacts, isolated)

• Coil Supply Voltage: 24 V DC

• Coil Current (all relays): Max 30 mA

• External Protection: Miniature fuse, max 6.3 A, quick-response, 1,500 A breaking capacity

• Operating Cycles Max: 1,000,000

• Rated Switching Voltage: 24120 V DC, 24230 V AC

• Thermal Continuous Current: Max 5 A

Diagnostics & Substitute Values

• Module Diagnostics: Yes

• Diagnostic Alarm: Yes

• Supply Voltage Monitoring: Yes

• Substitute Values Connectable: Yes

• LED Indicators:

  • PWR: Green (Supply voltage)

  • Channel Status: Green

  • Module Diagnostics: Green/Red

Potential Separation & Isolation

• Between Channels: Yes

• Between Channels and Backplane Bus / Supply Voltage: Yes

• Isolation Test: 2,000 V DC (routine)

• Backplane Bus & Supply Voltage: 707 V DC (type test)

Mechanical & Installation

• Connection: 2-wire / 3-wire with BU type U0

• Dimensions (W H D): 20 73 58 mm

• Weight: 40 g

• Horizontal Installation Temp: -30C to 60C

• Vertical Installation Temp: -30C to 50C

• Max Installation Altitude: 2,000 m

Certifications & Approvals

• General Product Approval: Manufacturer Declaration

• Hazardous Locations / Marine: FM, KC, NK, CCS

Classification

• eClass: 27-24-26-04

• ETIM 9 / 8 / 7: EC001599

• IDEA 4: 3566

• UNSPSC 15: 32-15-17-05

Technical Details
