About SIEMENS ET 200SP, RQ COni 3x120VDC.230VAC5A ST 6ES7132-6HC70-0BU0

Manufacturer SeriesS7 ET 200 CPUBRANDSIEMENSProduct type designationRQ 3x120VDC-230VAC/5A CO n.i. STSTEP 7 TIA Portal configurable/integrated from versionTIA V19 or higher with HSP0463 / integrated as of TIA V20MODEL NAME/NUMBER6ES7132-6HC70-0BU0SIMATIC ET 200SP, relay module, RQ COni 3x120VDC..230VAC/5A ST, 3 CO contacts non-isolated contacts, packing unit: 1 unit, suitable for BU type U0, color code CC20, substitute value output, module diagnostics for supply voltage

SIMATIC ET 200SP Relay Module

• Article No.: 6ES7132-6HC70-0BU0
• Type: RQ COni 3x120VDC..230VAC/5A ST
• Contacts: 3 CO, non-isolated
• Packing Unit: 1 unit
• Suitable for: BU type U0
• Color Code: CC20

General Information

• Firmware version: V0.0 (No FW update possible)

• Usable BaseUnit: BU type U0

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: No

• Engineering: STEP 7 TIA Portal V19+ / Integrated as of TIA V20

• PROFIBUS: GSD revision 3+

• PROFINET: GSDML V2.45

Supply Voltage

• Rated: 24 V DC

• Permissible range: 19.2 28.8 V DC

• Reverse polarity protection: Yes

• Current consumption: 40 mA (rated), max. 55 mA

Digital Outputs

• Type: Relays

• Number: 3

• Current-sinking & sourcing: Yes

• Parameterizable: Yes

• Short-circuit protection: No

• Switching capacity:

  • Resistive load: max. 5 A

  • Inductive load: max. 2 A

• Parallel switching of outputs:

  • Logic links: Yes

  • Uprating: No

  • Redundant control: Yes

• Switching frequency:

  • Resistive load: 2 Hz

  • Inductive load: 0.5 Hz

  • Lamp load: 2 Hz

• Total current per channel/module: 5 A

• Thermal continuous current: 5 A (Max. 1385 VA / 150 W)

• Switching voltage: 24120 V DC / 24230 V AC

• Minimum switching current: 10 mA / 5 V DC

Relay Outputs

• Number: 3 changeover contacts, non-floating

• Rated supply voltage of relay coil: 24 V DC

• Coil current (all relays): max. 40 mA

• External protection: Miniature fuse max. 6.3 A, quick-response, 1500 A breaking capacity

• Operating cycles: max. 1,000,000

Cable Length

• Shielded: max. 1000 m

• Unshielded: max. 200 m

Diagnostics & Status

• Diagnostic function: Yes

• Substitute values: Yes

• Monitoring: Supply voltage

• LEDs:

  • PWR (green)

  • Channel status (green)

  • Module diagnostics (green/red DIAG LED)

Isolation

• Between channels: No

• Channels backplane bus: Yes

• Channels power supply: Yes

• Isolation tested: 2000 V DC (routine), 707 V DC (type test)

Ambient Conditions

• Horizontal operation: -30 to 60 C

• Vertical operation: -30 to 50 C

• Max installation altitude: 2000 m

Dimensions & Weight

• Width: 20 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 40 g
