SIMATIC S7-1500 Compact CPU CPU 1511C-1PN

About SIMATIC S7-1500 Compact CPU CPU 1511C-1PN

Siemens SIMATIC S7-1500 Compact CPU 1511C-1 PN - High-Performance Compact PLC for Industrial Automation The Siemens SIMATIC S7-1500 Compact CPU 1511C-1 PN is a compact and efficient programmable logic controller (PLC) designed for small to medium-sized automation applications. With built-in digital and analog I/O, along with PROFINET connectivity, it ensures fast processing, seamless communication, and reliable automation control. Key Features: Integrated digital and analog I/O for space-saving automation solutions.High-speed data processing for precise control and fast response times.Built-in PROFINET interface for seamless industrial communication.1 MB memory for programs and 5 MB for data storage.Advanced diagnostics and cybersecurity features for secure operation.Direct integration with Siemens TIA Portal for easy configuration and programming.Compact and robust design for efficient use in space-constrained environments. At Naksh Technology, we offer genuine Siemens SIMATIC S7-1500 Compact CPU 1511C-1 PN with expert support. Enhance your industrial automation system with this powerful and space-efficient PLC solution.

Data Sheet: 6ES7511-1CK01-0AB0

Product: SIMATIC S7-1500 Compact CPU, CPU 1511C-1 PN

General Information

• Working Memory: 175 KB (program), 1 MB (data)

• I/O: 16 DI, 16 DO, 5 AI, 2 AO

• High-Speed Counters: 6

• High-Speed Outputs: 4 (PTO/PWM/frequency output)

• Interface: 1 PROFINET IRT, 2-port switch

• Bit Performance: 60 ns

• Front Connector: Push-in

• SIMATIC Memory Card: Required

Product Details

• HW Functional Status: FS03

• Firmware Version: V2.9

• I&M Data: Yes (I&M0I&M3)

• Isochronous Mode: Yes (min. OB 6 cycle of 625 s distributed)

• Engineering: STEP 7 TIA Portal (V17 or higher for FW V2.9)

Display and Control

• Screen Diagonal: 3.45 cm

• Keys: 8

• Mode Buttons: 2

Power Supply

• Rated Voltage: 24 V DC

• Voltage Range: 19.228.8 V DC

• Reverse Polarity Protection: Yes

• Mains Buffering: 5 ms

• Current Consumption: 0.81 A (without load), 9.810 A (CPU + load)

• Inrush Current: 1.9 A max

Digital Inputs (DI)

• Channels: 16

• Type: Source/sink, IEC 61131 type 3

• Input Voltage: 0 = -35 V, 1 = 1130 V

• Input Current: 2.5 mA typ.

• Input Delay: 020 ms (parameterizable)

• Cable Length: Shielded max. 1,000 m; Unshielded max. 600 m

Digital Outputs (DO)

• Channels: 16, Transistor (Push-pull)

• Output Voltage: 0 = max. 1 V, 1 = min. 23.2 V

• Current: 0.5 A per channel, 8 A per group

• Short-Circuit Protection: Yes

• Switching Frequency: Resistive load 100 kHz

Analog Inputs (AI)

• Channels: 5 (4 U/I, 1 R/RTD)

• Voltage Ranges: 010 V, 15 V, -1010 V, -55 V

• Current Ranges: 020 mA, 420 mA, -2020 mA

• Resistance/RTD: Pt100, Ni100

• Cycle Time (all channels): 1 ms

Analog Outputs (AO)

• Channels: 2

• Voltage Ranges: 010 V, 15 V, -1010 V

• Current Ranges: 020 mA, 420 mA, -2020 mA

• Short-Circuit Protection: Yes

• Settling Time: Resistive 1.5 ms, Capacitive 2.5 ms, Inductive 2.5 ms

Encoder

• Supported: Voltage, 4-wire current, 2/3/4-wire resistance

• Incremental Encoder: Yes, A/B signals, optional zero track

• Max Frequency: 100 kHz (input), 400 kHz (counting)

Accuracy & Errors

• Linearity Error: 0.1% (AI), 0.15% (AO)

• Temperature Error: 0.005 %/K

• Repeat Accuracy: 0.05%

• Operational Error Limit: 0.3%

• Basic Error Limit (25C): 0.2%

Interfaces

• PROFINET Ports: 2 (RJ45, 100 Mbps, integrated switch)

• Protocols: IPv4, PROFINET IO Controller/Device, SIMATIC, Open IE, Web Server, MODBUS TCP

• OPC UA: Client/Server (requires runtime license)

Integrated Functions

• Motion Control: Yes, 800 motion control resources

• PID Controllers: PID_Compact, PID_3Step, PID_Temp

• High-Speed Counters: 6 (max. 400 kHz)

• Incremental Position Detection: Yes

Potential Separation & Isolation

• Between DI/DO channels: No

• Between channels and backplane bus: Yes

• Isolation Test Voltage: 707 V DC

Ambient Conditions

• Operating Temperature: -25C to 60C (horizontal), -25C to 40C (vertical)

• Storage Temperature: -40C to 70C

• Altitude: Up to 5,000 m

Programming

• Languages Supported: LAD, FBD, STL, SCL, GRAPH

• Program/Block Protection: Yes

• Access Protection: Yes (Write/Read/Complete)

Dimensions & Weight

• Width: 85 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: 1,050 g
