About Siemens Active Line Module-6SL3130-7TE31-2AA3

DESCRIPTION Active Line Module (Booksize) with internal air cooling 120 kW NET WEIGHT 23,000 Kg SINAMICS S120 ACTIVE LINE MODULE INPUT: 3AC 380-480V, 50/60HZ OUTPUT: DC 600V, 200A, 120KW FRAME SIZE: BOOK SIZE INTERNAL AIR COOLING INCL. DRIVE-CLIQ CABLE

Active Line Module 6SL3130-7TE31-2AA3

Type: Active Line Module (Booksize)

Technical Data: Subject to change

Electrical Data

Input:

• Phases: 3 AC

• Line Voltage: 342 528 V

• Line Frequency: 47 63 Hz

• Short-Circuit Strength: 65 kA

• Over voltage Category: Class III

Line Power Factor:

• Active Mode: cos = 1 (total = 1)

• Smart Mode: Minimal cos = 0.96 (total 0.65 0.90)

DC Link Voltage:

• Active Mode (380400 V AC): 600 V

• Active Mode (400415 V AC): 625 V

• Smart Mode: 1.35 line voltage

Electronics Power Supply: 24 V DC (-15% / +20%)

Connections

• Line Side: M8 bolt (X1)

• Conductor Cross-Section: 2.5 120 mm (AWG 14 AWG -3)

• Alternative: 2 50 mm

• PE Conductor: M8 screw

• Max Line Length: Shielded 1,000 m; Unshielded 1,500 m

Mechanical Data

• Degree of Protection: IP20 / UL open type

• Type of Construction: Book size

• Net Weight: 23 kg

• Dimensions (W H D): 300 629 270 mm

Rated Data

Infeed Power:

• Rated: 120 kW (150 hp)

• S6 Duty: 145 kW

• Maximum: 175 kW

Regenerative Feedback Power:

• Rated: 120 kW (150 hp)

• S6 Duty: 145 kW

• Maximum: 175 kW

DC-Link Current:

• At 600 V DC: 200 A

• S6 Duty: 244 A

• Maximum: 292 A

Input Current:

• 380 V AC: 192 A

• 400 V AC: 182 A

• 480 V AC: 152 A

• 400 V AC S6 Duty: 220 A

• Maximum: 267 A

Current Requirement at 24 V DC: Max 2.5 A

Busbar Ampacity:

• Electronics Power Supply (24 V DC): 20 A

• DC-Link Connection: 200 A

DC Link Capacitance:

• Active Line Module: 3,995 F

• Drive System (Max): 20,000 F

General Technical Specifications

• Sound Pressure Level: 73 dB

• Power Loss: 2.24 kW

Ambient Conditions

• Operating Temperature: 0 40 C

• Cooling Air Throughput: 0.144 m/s

• Installation Altitude: Max 1,000 m

• Cooling Type: Internal Air Cooling (integrated fan for intensified cooling)

Technical Details
