Siemens Active Interface Module 6SL3100-0BE31-2AB0

The Siemens Active Interface Module 6SL3100-0BE31-2AB0 is a durable industrial module designed for smooth integration in manufacturing environments.

Key Details:

• Weight: 36.6 kg

• Operating Frequency: 50/60 Hz

• Rated Voltage: 380480 V

• "407" data-end="439" >

  Surface Finish: Polished

• Warranty: 1 Year

• Design: Standard size, robust and reliable

Data Sheet Active Interface Modules (Booksize)

Article No.: 6SL3100-0BE31-2AB0

General Information

• Type: Active Interface Module, Booksize

• Degree of protection: IP20 / UL open type

• Net weight: 36.6 kg (80.69 lb)

• Construction type: Booksize

Electrical Data

• Number of phases: 3 AC

• Line voltage: 380 480 V

• Input current: 192 A

• Current requirement at 24 V DC (max): 1.20 A

Connections

• Line side: M8 bolt

• Conductor cross-section: 2.5 120 mm (AWG 14 AWG -3)

• PE conductor: M8 screw

Mechanical Data

• Dimensions:

  • Width: 300 mm (11.81 in)

  • Height: 380 mm (14.96 in)

  • Depth: 270 mm (10.63 in)

General Technical Specifications

• Sound pressure level: 68 dB

• Power losses: 0.585 kW

Ambient Conditions

• Cooling type: Internal air cooling

• Cooling air throughput: 0.167 m/s (5.900 ft/s)
