SIEMENS ET200SP 8DI MODULE

About SIEMENS ET200SP 8DI MODULE

Boost your industrial automation systems with theSIEMENS ET200SP 8DI MODULE, a high-performance digital input module designed for the Siemens ET200SP I/O system. This compact yet powerful module provides eight channels for digital inputs, enabling efficient signal processing and seamless integration with a wide range of industrial devices.The SIEMENS ET200SP 8DI MODULEensures fast, reliable data transmission for applications requiring accurate detection of digital signals. Whether you are working with sensors, switches, or other digital devices, this module delivers exceptional performance, enhancing the reliability of your automation systems. Its robust design makes it suitable for demanding industrial environments, ensuring consistent operation even in challenging conditions.At Naksh Technology Solution LLP, we offer expert integration and support for theSIEMENS ET200SP 8DI MODULE, ensuring smooth functionality and optimal performance within your automation setup. Improve the efficiency of your industrial operations with theSIEMENS ET200SP 8DI MODULE, engineered to provide high-quality digital input processing for your Siemens automation systems

 General Information

• Product Type: DI 8x24 VDC ST

• HW Status: From FS02

• Firmware Version: V0.0 (No update possible)

• Usable BaseUnits: BU type A0

• Module Color Code: CC01

Product Functions

• I&M Data: Yes (I&M0 to I&M3)

• Isochronous Mode: No

• PROFINET Compatible: Yes

Engineering

• STEP 7 TIA Portal: From V14

• STEP 7: From V5.5 SP3

• PCS 7: From V8.1 SP1

• PCS neo: From V3.1

• PROFIBUS GSD: Revision 3 and 5+

• PROFINET GSDML: V2.3

Operating Mode

• DI: Yes

• Counter / Oversampling / MSI: No

Supply Voltage

• Rated Value: 24 V DC

• Permissible Range: 19.2 28.8 V

• Reverse Polarity Protection: Yes

Input Current & Encoder Supply

• Max Current: 50 mA (all channels via encoder supply)

• Encoder Supply Outputs: 8

• Output Voltage (min): 19.2 V

• Short-Circuit Protection: Yes

• Max Output Current (per channel/module): 700 mA

Power Loss

• Typical: 1 W (24 V, 8 inputs via encoder supply)

Address Area

• Per Module: 1 byte + 1 byte for QI info

Hardware Configuration

• Automatic Encoding: Yes (Mechanical coding element Type A)

• BaseUnit Connections:

  • 1-wire: BU type A0

  • 2-wire: BU type A0

  • 3-wire: BU type A0 + AUX or potential distributor

  • 4-wire: BU type A0 + potential distributor

Digital Inputs

• Number of Inputs: 8

• Parameterizable: Yes

• Input Type: Source/sink (PNP, P-reading)

• IEC 61131 Type: 3

• Rated Voltage: 24 V DC

• Signal Voltage:

  • "0": -30 to +5 V

  • "1": +11 to +30 V

• Input Current for Signal "1": Typ. 2.5 mA

• Input Delay: 0.0520 ms (parameterizable)

• Cable Length:

  • Shielded: Max 1,000 m

  • Unshielded: Max 600 m

Diagnostics / Status

• Module Diagnostics: Yes

• Monitored Events: Short-circuit, wire break, supply voltage, encoder power

• Alarms: Yes

• Diagnostic LEDs:

  • PWR: Green

  • Channel Status: Green

  • Module Diagnostics: Green/Red DIAG

Potential Separation & Isolation

• Channels: No separation between channels

• Channels & Backplane Bus: Yes

• Channels & Power Supply: No

• Isolation Tested: 707 V DC

Standards & Approvals

• Safety Functions: Not suitable

• Environmental Product Declaration: Yes

• Global Warming Potential (CO2 eq):

  • Total: 15.9 kg

  • Production: 3.69 kg

  • Operation: 12.7 kg

  • End of Life: -0.495 kg

Ambient Conditions

• Horizontal Installation: -30 C to 60 C (<0 C from FS02)

• Vertical Installation: -30 C to 50 C (<0 C from FS02)

• Max Altitude: 5,000 m (restrictions above 2,000 m)

Mechanics / Dimensions

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: ~28 g
