About SIEMENS G120 AC DRIVE-6SL3210-1KE12-3UF2

The Siemens G120 AC Drive-6SL3210-1KE12-3UF2 is a reliable industrial application drive with a protection level of IP20, a digital display for easy monitoring, and a frequency range of 47-63 Hertz (Hz). It operates at a rated voltage of 380-480 Volt (V) and comes with a warranty of 1 year. The compact dimensions of 173X73X160 millimeters (mm) make it suitable for various industrial settings.

Data Sheet SINAMICS G120C

Article No.: 6SL3210-1KE12-3UF2
Technical data are subject to change. There may be discrepancies between calculated and rating plate values.

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380 480 V (+10% / -20%)

• Line frequency: 47 63 Hz

• Rated current (LO): 2.90 A

• Rated current (HO): 2.50 A

Output

• Number of phases: 3 AC

• Rated voltage: 400V IEC / 480V NEC

• Rated power (LO): 0.75 kW / 1.00 hp

• Rated power (HO): 0.55 kW / 0.75 hp

• Rated current (LO): 2.20 A

• Rated current (HO): 1.70 A

• Rated current (IN): 2.30 A

• Max. output current: 3.40 A

• Pulse frequency: 4 kHz

• Output frequency (vector control): 0 240 Hz

• Output frequency (V/f): 0 550 Hz

Overload Capability

Low Overload (LO)

• 150% IL for 3 s

• Then 110% IL for 57 s

• Cycle time: 300 s

High Overload (HO)

• 200% IH for 3 s

• Then 150% IH for 57 s

• Cycle time: 300 s

General Technical Specifications

• Power factor : 0.70 0.85

• Offset factor cos : 0.95

• Efficiency : 0.97

• Sound pressure level (1m): 49 dB

• Power loss: 38.6 W

• Integrated filter class: Unfiltered

Communication

• PROFINET, EtherNet/IP

Inputs / Outputs

Standard Digital Inputs

• Number: 6

• Switching level 0 1: 11 V

• Switching level 1 0: 5 V

• Max. inrush current: 15 mA

Fail-safe Digital Inputs

• Number: 1

Digital Outputs

• Relay changeover: 1 (DC 30 V, 0.5 A)

• Transistor output: 1 (DC 30 V, 0.5 A)

Analog / Digital Inputs

• Number: 1 (Differential input)

• Resolution: 10 bit

• Digital switching thresholds:

  • 0 1: 4 V

  • 1 0: 1.6 V

Analog Outputs

• Number: 1 (Non-isolated)

PTC/KTY Interface

• Supports: PTC, KTY, Thermo-Click

• Accuracy: 5 C

Closed-loop Control Techniques

Ambient Conditions

• Cooling: Air cooling (integrated fan)

• Cooling air requirement: 0.005 m/s

• Installation altitude: 1,000 m

• Ambient temperature (operation): -10 40 C

• Transport: -40 70 C

• Storage: -25 55 C

• Max. relative humidity: 95% (no condensation or icing)

Connections

Signal Cable

• Conductor size: 0.15 1.50 mm (AWG 24 16)

Line Side

• Version: Plug-in screw terminals

• Conductor size: 1.00 2.50 mm (AWG 18 14)

Motor End

• Version: Plug-in screw terminals

• Conductor size: 1.00 2.50 mm (AWG 18 14)

DC Link (Braking Resistor)

• Version: Plug-in screw terminals

• Conductor size: 1.00 2.50 mm (AWG 18 14)

Other

• Line length max.: 15 m

• PE connection: M4 screw on housing

• Max. motor cable length:

  • Shielded: 150 m

  • Unshielded: 150 m

Mechanical Data

• Degree of protection: IP20 / UL Open Type

• Frame size: FSAA

• Net weight: 1.40 kg

• Dimensions:

  • Width: 73 mm

  • Height: 173 mm

  • Depth: 160 mm
