Siemens G120 Ac Drive 6SL3210-1PE21-1UL0

Price 22475.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Siemens G120 Ac Drive 6SL3210-1PE21-1UL0 Specification

Humidity %
95 %

Mounting Type
DIN Rail

Power Rating
4.00 kW

Application
Automation

Protection Level
IP20

Frequency (MHz)
47-63 Hertz (HZ)

Rated Voltage
380-480 Volt (V)

Color
Black

Dimension (L*W*H)
100 x 292 x 165 Millimeter (mm)

Weight
2.90 Kilograms (kg)

Operating Temperature
-10 to 40 Celsius (oC)

Warranty
1 Year

Phase
3 AC

About Siemens G120 Ac Drive 6SL3210-1PE21-1UL0

SINAMICS POWER MODULE PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER 3AC380-480V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 3KW FOR 200% 3S,150% 57S,100% 240S AMBIENT TEMP -10 TO +50 DEG C OUTPUT LOW OVERLOAD: 4KW FOR 150% 3S,110% 57S,100% 240S AMBIENT TEMP -10 TO +40 DEG C 291 X 100 X 165 (HXWXD), FSB PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.6

SINAMICS Power Module PM240-2

Article No.: 6SL3210-1PE21-1UL0
Type: Power Module
Phases: 3 AC
Cooling: Internal air cooling (IP20 / UL open type)
Frame Size: FSB

Input Data

Line Voltage: 380480 V 10%
Line Frequency: 4763 Hz
Rated Current:
- Low Overload (LO): 13.30 A
- High Overload (HO): 11.60 A

Output Data

Phases: 3 AC
Rated Voltage: 400 V IEC / 480 V NEC
Rated Power:
- LO: 4 kW / 5 hp
- HO: 3 kW / 4 hp
Rated Current:
- LO: 10.20 A
- HO: 7.70 A
Maximum Output Current: 15.40 A
Pulse Frequency: 4 kHz
Output Frequency:
- Vector Control: 0200 Hz
- V/f Control: 0550 Hz

Overload Capability

Mode	Overload	Duration	Cycle Time
LO	1.1 rated	57 s	300 s
LO	1.5 rated	3 s	300 s
HO	1.5 rated	57 s	300 s
HO	2 rated	3 s	300 s

General Technical Data

Power Factor (): 0.85
Offset Factor (cos ): 0.95
Efficiency (): 0.97
Sound Pressure Level: 72 dB @1m
Power Loss: 0.11 kW

Connections

Line Side: Plug-in screw terminals, 1.56 mm (AWG 1610)
Motor Side: Plug-in screw terminals, 1.56 mm (AWG 1610)
Max Motor Cable Length:
- Shielded: 50 m
- Unshielded: 100 m

Mechanical Data

Dimensions (W H D): 100 292 165 mm
Net Weight: 2.90 kg (6.39 lb)
Degree of Protection: IP20 / UL open type

Ambient Conditions

Operation LO: -10 40 C
Operation HO: -10 50 C
Storage / Transport: -25 55 C
Relative Humidity: Max. 95% RH, no condensation
Installation Altitude: 1,000 m

Specification	Details
Product Name / Model	6SL3210-1PE21-1UL0
Voltage	380 - 480 V
Rated power	4.00 kW
Rated current	13.30 A
Phases	3 AC
Frequency	47-63 Hz
IP protection	IP20
Humidity	95 %
Operation temperature	-10 - +40 Degree C
Dimensions	100 x 292 x 165 mm
Net weight	2.90 kg
