SIEMENS G120C AC DRIVE-6SL3210-1KE14-3UB2

About SIEMENS G120C AC DRIVE-6SL3210-1KE14-3UB2

Enclosure TypeIP21Communication Interface Mod bus DESCRIPTION SINAMICS G120C RATED POWER 1.5KW/2.0 HP AC DRIVE Normal ModbusNETWEIGHT1,100 Kg Motor Power1.5kW SINAMICS G120C rated power 3AC380-480V +10/-20% 47-63Hz low overload: 1,5kW at 150% 3s, 110% 57s, 100% 240s high overload: 1,1kW at 200% 3s, 150% 57s, 100% 240s unfiltered external 24V I/O interface: 6DI, 2DO,1AI,1AO, 1Mot_t Safe Torque Off integrated Field bus: USS/ MOD BUS RTU Protection: IP20/ UL OPEN TYPE Size: FSAA 173X73X155(HXWXD)

Article No.: 6SL3210-1KE14-3UB2

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380 480 V +10% / -20%

• Line frequency: 47 63 Hz

• Rated current (LO): 5.50 A

• Rated current (HO): 4.50 A

Output

• Number of phases: 3 AC

• Rated voltage: 400V IEC / 480V NEC (1)

• Rated power (LO): 1.50 kW / 2.00 hp

• Rated power (HO): 1.10 kW / 1.50 hp

• Rated current (LO): 4.10 A

• Rated current (HO): 3.10 A

• Rated current (IN): 4.30 A

• Max. output current: 6.20 A

• Pulse frequency: 4 kHz

• Output frequency (vector control): 0 240 Hz

• Output frequency (V/f control): 0 550 Hz

Overload Capability

Low Overload (LO)

• 150% IL for 3 s

• Then 110% IL for 57 s (in 300 s cycle)

High Overload (HO)

• 200% IH for 3 s

• Then 150% IH for 57 s (in 300 s cycle)

General Technical Specifications

• Power factor : 0.70 0.85

• Offset factor cos : 0.95

• Efficiency : 0.97

• Sound pressure level (1 m): 49 dB

• Power loss: 60.3 W

• Filter class (integrated): Unfiltered

Communication

• USS / MODBUS RTU

Inputs / Outputs

Standard Digital Inputs

• Number: 6

• Switching level 0 1: 11 V

• Switching level 1 0: 5 V

• Max. inrush current: 15 mA

Fail-safe Digital Inputs

• Number: 1

Digital Outputs

• Relay changeover contact: 1

  • DC 30 V, 0.5 A (resistive load)

• Transistor output: 1

  • DC 30 V, 0.5 A (resistive load)

Analog / Digital Inputs

• Number: 1 (differential input)

• Resolution: 10 bit

• Switching threshold (as digital input):

  • 0 1: 4 V

  • 1 0: 1.6 V

Analog Outputs

• Number: 1 (non-isolated)

PTC / KTY Interface

• Supports: PTC, KTY, Thermo-Click

• Accuracy: 5C

Closed-loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with FCC: Yes

• V/f ECO linear / square-law: Yes

• Sensorless vector control: Yes

• Vector control with sensor: No

• Encoderless torque control: No

• Torque control with encoder: No

Ambient Conditions

Cooling

• Air cooling (integrated fan)

• Cooling air requirement: 0.005 m/s

Altitude

• Up to 1,000 m

Temperatures

• Operation: -10 40C

• Transport: -40 70C

• Storage: -25 55C

Humidity

• Max. operation: 95% at 40C
  (No condensation/icing)

Connections

Signal Cable

• Conductor: 0.15 1.50 mm (AWG 24 16)

Line Side

• Plug-in screw terminals

• Conductor: 1.00 2.50 mm (AWG 18 14)

Motor End

• Plug-in screw terminals

• Conductor: 1.00 2.50 mm (AWG 18 14)

DC Link (braking resistor)

• Plug-in screw terminals

• Conductor: 1.00 2.50 mm

Line Length

• Max.: 15 m

PE Connection

• On housing with M4 screw

Max. Motor Cable Length

• Shielded: 150 m

• Unshielded: 150 m

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSAA

• Net weight: 1.40 kg

Dimensions

• Width: 73 mm

• Height: 173 mm

• Depth: 155 mm
