Siemens HMI 6AV2123-2DB03-0AX0

About Siemens HMI 6AV2123-2DB03-0AX0

SIMATIC HMI, KTP400 Basic, Basic Panel, Key/touch operation, 4" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic V13, contains open-source software, which is provided free of charge see enclosed CD.

General Information

• Product Type: KTP400 Basic, Basic Panel

• Operation: Key/touch operation

• Display: 4.3" TFT widescreen, LED backlighting, 65,536 colors

• Resolution: 480 272 pixels

• Screen Dimensions: Width 95 mm Height 53.9 mm

• Backlight: MTBF 20,000 h, dimmable

• Configuration Software: WinCC Basic V13 / STEP 7 Basic V13

• Open-source Software: Included (see CD)

Control Elements

• Function Keys: 4 (no LEDs)

• System Keys: None

• Numeric/Alphanumeric Keyboard: Onscreen

• Touch Screen: Analog-resistive

Installation / Mounting

• Mounting Position: Vertical

• Wall / Direct Mounting: No

• Portrait & Landscape Format: Yes

• Max Tilt without Ventilation: 35

Supply Voltage / Power

• Rated Voltage: 24 V DC

• Permissible Range: 19.2 28.8 V DC

• Current Consumption: 125 mA

• Inrush Current (It): 0.2 As

• Active Power Input: Typ. 3 W

Processor / Memory

• Processor: ARM

• Memory: Flash + RAM

• User Data Memory: 10 MB

Audio / Clock

• Buzzer: Yes

• Speaker: No

• Hardware Clock: Yes, retentive (6 weeks backup), synchronizable

• Software Clock: Yes

Interfaces

• Industrial Ethernet: 1

• USB: 1 (up to 16 GB)

• Other Interfaces: None

• PROFINET: Yes

• EtherNet/IP: Yes

• MODBUS TCP/IP: Yes

Diagnostics / Status

• Diagnostic Information: Not readable

• LED Indicators: Status LEDs on panel

EMC / Protection

• Emission: EN 55011, Class A

• Degree of Protection: IP65 (front), IP20 (rear)

• NEMA (Front): Type 4, 4X

Standards / Approvals

• CE, cULus, RCM, KC: Yes

• Hazardous Area: Not suitable

• Marine Approvals: GL, ABS, BV, DNV, LRS, NK

Ambient Conditions

• Indoor Use: Yes

• Outdoor Use: No

• Operating Temp: 0 50 C (vertical installation)

• Max Tilt Temp: 0 40 C

• Storage Temp: -20 60 C

• Relative Humidity: Max. 90%, non-condensing

HMI Functionality

• Message System: Alarm classes 32, bit messages 1000, analog messages 25

• Recipe Management: 50 recipes, 100 records per recipe, 256 kB internal memory

• Variables: 800 per device, 100 per screen, arrays supported

• Images: 250 configurable, 100 objects per image

• Complex Objects: 10 per screen (Alarm, Trend, User, Recipe, System diagnostics views)

• Archiving: 2 archives/device, 10,000 entries each (message & process values)

• Security: 50 users, 50 groups, 32 user rights, password export/import

Peripherals / Storage

• USB Memory: Yes (for backup & restore)

• Memory Cards: No (MM, SD, CF)

Mechanics

• Enclosure Material: Plastic

• Dimensions: Width 140 mm Height 116 mm Depth 34.9 mm

• Mounting Cutout: Width 124 mm Height 100 mm

• Weight: 360 g (without packaging), 470 g (with packaging)
