SIMATIC HMI KP8F PN, Key Panel, 8 short-stroke switches with multi-colored LEDs, PROFINET interfaces with PROFIsafe; 8 DI/DO and 2 safety DI pins, 24 V DC can be looped through parameterizable as of STEP 7 V5.5

Data Sheet 6AV3688-3AF37-0AX0

SIMATIC HMI KP8F PN Key Panel
8 short-stroke switches with multi-colored LEDs, PROFINET with PROFIsafe, 8 DI/DO + 2 safety DI pins, 24 V DC

General Information

• Product type designation: KP8F PN

Control Elements

• Parameterizable keys: Yes

• Membrane keyboard: User-definable label membrane keys

• Function keys: 8

• Short-stroke keys: 8

Process Control Expansions

• DP direct LEDs: 8 (brightness adjustable)

• LED color modes: 5 (red, green, blue, yellow, white)

• Direct keys: 8

Installation / Mounting

• Mounting type: Mounting clip

• Mounting position: Vertical

• Front mounting: Yes

• Portrait/Landscape: Both possible

• Max tilt angle (no external ventilation): 30

• Slots for command devices: 0

Supply Voltage

• Type: DC

• Rated value: 24 V (looped through, interrupted when pulled)

• Range: 20.428.8 V

Input Current

• Current consumption (rated): 0.3 A

Digital Inputs

• Number: 8 (max 8 I/O + 2 SIL2 or 1 SIL3)

• Input voltage: 24 V DC

Digital Outputs

• Number: 8

• Short-circuit protection: Yes

• Switching capacity: Max 100 mA

• Output voltage: 24 V DC (non-isolated)

• Current per channel: Max 100 mA

• Current per group: Max 800 mA

Interfaces

• Industrial Ethernet interfaces: 2

• PROFINET interfaces: 2 (with switch)

• Status LEDs: 2 per port

Protocols

• PROFINET: Yes

• PROFIsafe: Yes (1 SIL3 or 2 SIL2)

• IRT: Yes

• Others (MPI, CAN, Modbus, EtherNet/IP, etc.): No

Commissioning Functions

• Illuminant test: Yes (on startup)

• Key & lamp test: Yes

EMC

• EN 55011 Class A: Yes (industrial)

• Class B: No

Protection Class

• Front: IP65

• Rear: IP20

• NEMA 4X front: Yes

Standards & Approvals

• CE, cULus, RCM, KC, EAC: Yes

• ATEX Zone 2 / 22: Yes

• FM Class I Div 2: Yes

• Marine approvals: No

Ambient Conditions

• Operating temperature: 055 C

• Storage/Transport: -20 to 60 C

• Relative humidity: Max 95% (no condensation)

Configuration

• STEP 7 Basic/Professional (TIA Portal): Yes

• S7-1200 / S7-1500 / S7-300/400: Supported

Mechanics / Materials

• Front material: Plastic

• Short-stroke keys lifespan: 1,500,000 cycles

• LED lifetime: 100% duty

Dimensions

• Front width: 98 mm

• Front height: 155 mm

• Cutout: 67.7 129.7 mm

• Overall depth: 49 mm

• Weight: 280 g
