SIEMENS LOGO PLC 6ED1055-1CB00-0BA2

The SIEMENS LOGO PLC 6ED1055-1CB00-0BA2 is a compact and reliable automation solution designed for versatile industrial applications. Featuring an operating temperature range of -20 to +50C, it ensures stable performance in varied environmental conditions. With an IP20 protection level, it is safeguarded against dust and small objects, making it ideal for indoor operations. Its design supports convenient DIN rail mounting for seamless integration into control panels. Powered by 24V DC with a frequency of 50/60Hz, this PLC is energy-efficient while maintaining consistent operation. Compact dimensions of 35.5 x 90 x 58mm enable easy installation even in space-constrained setups. The units grey color and robust design complement its professional appearance, allowing it to seamlessly blend into industrial environments. Additionally, it guarantees operational efficiency in humid conditions with tolerance levels of up to 95% humidity. Whether for monitoring or controlling processes, this PLC is perfectly suited to meet automation requirements with precision and reliability.

Data Sheet 6ED1055-1CB00-0BA2

LOGO! DM8 24 Expansion Module PS/I/O: 24V/24V/Transistor, 4 DI / 4 DO For LOGO! 8

Installation / Mounting

• Mounting on 35 mm DIN rail

• Width: 2 spacing units

Supply Voltage

• Rated value (DC): 24 V

• Permissible range: 20.4 28.8 V DC

Digital Inputs

• Number of inputs: 4

• Input voltage type: DC

  • Signal "0": < 5 V DC

  • Signal "1": > 12 V DC

• Input current:

  • Signal "0": max. 0.88 mA

  • Signal "1": typ. 2.1 mA

• Input delay:

  • 0 1: max. 1.5 ms

  • 1 0: max. 1.5 ms

Digital Outputs

• Number of outputs: 4

• Short-circuit protection: Yes

• Output current: 0.3 A

• Parallel switching for uprating: No

• Switching frequency:

  • Resistive load: max. 10 Hz

  • Inductive load: max. 0.5 Hz

EMC

• Emission of radio interference: EN 55011, Limit Class B (residential areas)

Protection

• Degree of protection: IP20

Standards / Approvals

• CE mark: Yes

• CSA approval: Yes

• UL approval: Yes

• FM approval: Yes

• IEC 61131 compliant: Yes

• VDE 0631 compliant: Yes

• Marine approval: Yes

Ecological Footprint

• Environmental product declaration: Yes

• Global warming potential (CO eq):

  • Total: 59.1 kg

  • Production: 5.82 kg

  • Operation: 53.6 kg

  • End of life: -0.373 kg

Ambient Conditions

• Operating temperature: -20 C to 55 C (No condensation)

Dimensions

• Width: 35.5 mm

• Height: 90 mm

• Depth: 58 mm
