SIEMENS LOGO PLC 6ED1055-1MB00-0BA2

The SIEMENS LOGO PLC 6ED1055-1MB00-0BA2 is a compact and reliable automation solution designed for seamless integration into industrial applications. Engineered with a rated voltage of 24V DC, it ensures stable and efficient operation. Operating within a temperature range of -20C to +55C, this PLC is ideal for varied environments, while its humidity tolerance up to 95% guarantees performance even in challenging conditions. Featuring an IP20 protection level, it safeguards against solid objects and offers dependable durability. With dimensions of 35.5 x 90 x 58 mm, it is optimized for space-saving installations on DIN rails. Designed with a frequency compatibility of 50/60 Hz, the PLC delivers consistent performance in automation systems. The sleek grey design complements industrial setups, making it both functional and aesthetically suitable.

Siemens LOGO! DM8 12/24R Expansion Module

Product Code: 6ED1055-1MB00-0BA2
Type: PS/I/O: 12, 24V/12V/24V/Relay, 2 MW, 4 DI / 4 DO for LOGO! 8

Installation:

• Mounting: 35 mm DIN rail

• Width: 2 spacing units

Supply Voltage:

• Rated Value: 12 V DC / 24 V DC

• Permissible Range: 10.8 V 28.8 V

Digital Inputs:

• Number of Inputs: 4

• Input Voltage: DC

  • Signal "0": < 5 V

  • Signal "1": > 8.5 V

• Input Current:

  • Signal "0": max. 0.88 mA

  • Signal "1": typ. 1.5 mA

• Input Delay:

  • 0 1: max. 1.5 ms

  • 1 0: max. 1.5 ms

Digital Outputs:

• Number of Outputs: 4 (Relays)

• Short-circuit Protection: No

• Switching Capacity (Lamp Load): max. 1000 W

• Output Current (Signal "1"): Rated 5 A, Minimum Load 100 mA

• Parallel Switching: Not supported

• Switching Frequency:

  • Resistive load: max. 2 Hz

  • Inductive load: max. 0.5 Hz

  • Mechanical: max. 10 Hz

• Relay Contacts:

  • Inductive load: max. 3 A

  • Resistive load: max. 5 A

EMC & Standards:

• Radio Interference Emission: EN 55 011, Class B (residential)

• CE, CSA, UL, FM Approved

• Developed according to IEC 61131

• Marine Approval: Yes

Environmental / Ecological:

• Environmental Product Declaration: Yes

• Global Warming Potential:

  • Total: 59.1 kg CO eq

  • Production: 5.82 kg

  • Operation: 53.6 kg

  • End of Life: 0.373 kg

Ambient Conditions:

• Operating Temperature: 20C to 55C (No condensation)

Dimensions & Weight:

• Width: 35.5 mm

• Height: 90 mm

• Depth: 58 mm
