Siemens PLC 6ES7211-1BE40-0XB0

About Siemens PLC 6ES7211-1BE40-0XB0

Unlock advanced automation with the Siemens PLC 6ES7211-1BE40-0XB0, a reliable and compact solution for your control systems. This Siemens PLC 6ES7211-1BE40-0XB0offers robust performance, ideal for small to medium-sized automation tasks, making it a perfect choice for industries such as manufacturing, process control, and machine building. With its high processing power and flexible modular design, the Siemens PLC 6ES7211-1BE40-0XB0enables precise control and efficient operation, ensuring your systems run smoothly.The Siemens PLC 6ES7211-1BE40-0XB0is part of the Siemens S7-1200 family, providing seamless integration with other Siemens products for optimized automation. It supports a wide range of I/O modules and offers outstanding scalability for expanding your control system as your business grows. This Siemens PLC 6ES7211-1BE40-0XB0ensures low energy consumption, high-speed processing, and advanced connectivity options, making it the go-to choice for high-performance automation applications.At Naksh Technology Solution LLP, we provide expert support and integration for the Siemens PLC 6ES7211-1BE40-0XB0, ensuring it fits seamlessly into your existing systems. Enhance your industrial automation with the reliable, cost-effective, and scalable Siemens PLC 6ES7211-1BE40-0XB0.

General Information

• Product type: CPU 1211C AC/DC/relay

• Firmware version: V4.7

• Programming software: STEP 7 V20 or higher

Supply Voltage

• Rated value: 120 V AC / 230 V AC

• Permissible range: 85264 V AC

• Line frequency: 4763 Hz

• Current consumption:

  • 120 V AC: 60 mA (typ.), 180 mA (max)

  • 240 V AC: 30 mA (typ.), 90 mA (max)

• Inrush current max: 20 A

Power

• Power loss (typ.): 10 W

Memory

• Work memory: 75 KB

• Load memory: 1 MB (integrated + SIMATIC Memory Card)

• Backup: maintenance-free, battery not required

CPU Performance

• Bit operations: 0.08 s / instruction

• Word operations: 1.7 s / instruction

• Floating point arithmetic: 2.3 s / instruction

Digital Inputs

• Number: 6

• Type: Source/sink, HSC capable

• Rated voltage: 24 V DC

• Input current (typ.): 4 mA

• Parameterizable delays: 0.120 s / 0.0520 ms

• Cable length: Shielded max 500 m, unshielded max 300 m

Digital Outputs

• Number: 4 (Relay)

• Switching capacity:

  • Resistive load: 2 A max

  • Lamp load: 30 W DC / 200 W AC

• Output delay: 01 / 10 max 10 ms

• Relay operating cycles: 10 million mechanically, 100,000 at rated load

Analog Inputs

• Number: 2

• Input range: 010 V

• Input resistance: 100 k

• Resolution: 10-bit

• Conversion time: 625 s

• Cable length: max 100 m, shielded

Encoder Support

• Connectable encoders: 2-wire sensors

Interfaces

• PROFINET (RJ45): 1 port, max 100 Mbit/s, isolated, autonegotiation, autolinking

  • Controller: Yes

  • Device: Yes

• PROFIBUS: via CM 1243-5/1242-5

• AS-Interface: via CM 1243-2

• Ethernet protocols: TCP/IP, SNMP, DCP, LLDP

• Web server: Yes

• OPC UA: Yes (Basic license, up to 10 sessions, 1,000 monitored items max)

• MODBUS: TCP supported

Functions

• Counters: 6 (max. 100 kHz)

• Frequency measurement: Yes

• Position-controlled axes: max. 8 (via pulse interface up to 4)

• PID controller: Yes

• Forcing: Yes

• Diagnostic buffer: Yes

• Traces: 2, max 512 kB each

Potential Separation

• Digital inputs: 500 V AC for 1 min (between groups)

• Digital outputs: No separation between channels

EMC & Safety

• Electrostatic discharge: 8 kV air, 6 kV contact

• Supply line interference: IEC 61000-4-4 / IEC 61000-4-5 / IEC 61000-4-6

• Emission limits: EN 55011 Class A (industrial), Class B (residential with measures)

• IP protection: IP20

Operating Conditions

• Temperature: -20 C to 60 C (horizontal), -20 C to 50 C (vertical)

• Storage: -40 C to 70 C

• Altitude: -1,000 m to 5,000 m above sea level

• Humidity: max. 95%, no condensation

• Vibration/Shock: IEC 60068-2-6 & -27 compliant

Dimensions & Weight

• Width: 90 mm

• Height: 100 mm

• Depth: 75 mm

• Weight: 420 g
