About Siemens PLC IO Module ET200S 6ES7134-4FB52-0AB0

The Siemens PLC IO Module ET200S 6ES7134-4FB52-0AB0 is a high-quality industrial automation device designed for efficient control and monitoring applications. This module, in a sophisticated grey color, comes with a 1-year warranty and is in brand new condition. Operating on electric power mode, this module is suitable for standard size industrial setups. It is manufactured by a reliable business entity engaged in exporting, manufacturing, supplying, and trading industrial automation equipment.

Data Sheet: 6ES7134-4FB52-0AB0

SIMATIC DP ET 200S Electronics Module (2 AI High-Speed, 15 bit)

Spare Part

General Information

• Product: ET 200S 2 AI High Speed U, 15 bit

• Module width: 15 mm

• Cycle time: 0.1 ms

• SF LED: Yes (group fault)

• Isochronous mode: Yes

Supply Voltage

• Load voltage L+ (DC): 24 V (rated)

• Reverse polarity protection: Yes

Input Current

• From load voltage L+ (no load): max. 130 mA

• From backplane bus (3.3 V): max. 10 mA

Power Loss

• Typical power loss: 2 W

Address Area

• Address space per module: max. 4 bytes

Analog Inputs

• Number of inputs: 2

• Destruction limit voltage: max. 35 V (permanent)

• Maximum cycle time (all channels): 250 s

Supported Input Ranges (Voltage)

Cable Length

• Shielded: max. 200 m

Analog Value Generation

• Resolution (incl. sign):

  • 15 bit: 15 V, 2.5 V

  • 16 bit: 10 V, 5 V

• Conversion time per channel: 15 s

Smoothing (Parameterizable)

• None (1 cycle time)

• Low (4 cycle time)

• Medium (16 cycle time)

• High (32 cycle time)

Encoder Connection

• Suitable for voltage measurement: Yes

Errors / Accuracy

Operational error limit (full temperature range)

• Voltage: 0.3% of input range

Basic error limit (at 25 C)

• Voltage: 0.2% of input range

Diagnostics / Status

Alarms

• Hardware interrupt: Yes

Diagnostics

• Diagnostic information readable: Yes

• Wire-break (15 V): Yes

• Group error: Yes

• Overflow/underflow: Yes

LED Indication

• SF (red): Yes

Parameters

• Parameter memory: 12 bytes (4 bytes in compatibility mode)

• Group diagnostics: Enable / Disable

• Overflow/underflow: Enable / Disable

Potential Separation

• Between channels: No

• Between channels & backplane bus: Yes

• Between channels & load voltage L+: Yes

• Isolation test: 500 V DC

Dimensions

• Width: 15 mm

• Height: 81 mm

• Depth: 52 mm

Weight

• Approx.: 40 g
