About SIEMENS PLC MODULES 6ES7288-2DT08-0AA0

The Siemens PLC Modules 6ES7288-2DT08-0AA0 are designed for industrial use, offering reliability and efficiency in various applications. With a standard size and sleek black color, these modules have dimensions measuring 45 x 100 x 81 mm and weigh 147 g. They are specifically built for rack mounting, making them ideal for industrial automation systems. As an exporter, manufacturer, supplier, and trader of these PLC modules, we ensure top-notch quality and performance for seamless integration into your industrial setup.

Siemens SIMATIC S7-200 SMART

Digital Output Module SM DT08

8 DO, 24 V DC, Transistor 0.75 A

General Information

• Product type: SM DT08, DQ 8x24 V DC / 0.75 A

Supply Voltage & Consumption

• Rated voltage: 24 V DC

• Permissible range: 20.428.8 V DC

• Current consumption (from backplane bus 5 V DC): 95 mA (typical)

Digital Outputs

• Number of outputs: 8 (in groups of 2)

• Current type: Sourcing, not sinking

• Short-circuit protection: No

• Controlling a digital input: Yes

Output Ratings

• Resistive load: max. 0.75 A

• Lamp load: max. 5 W

• Voltage:

  • Rated: 24 V DC

  • Signal "0" max: 0.1 V

  • Signal "1" min: 20 V DC

• Current:

  • Signal "1" rated value: 0.75 A

  • Residual current for "0": max. 10 A

Switching & Delay

• Output delay (resistive load):

  • 0 1: max. 50 s

  • 1 0: max. 200 s

• Parallel switching of two outputs: Yes (logic links, uprating, redundant control)

• Total current per group: max. 3 A (depending on installation and temperature)

Cable Length

• Shielded: max. 500 m

• Unshielded: max. 150 m

Diagnostics & Status

• LED indication: Status of outputs

Potential Separation & Isolation

• Between channels: Yes, via optocoupler

• Isolation tested: 500 V AC for 1 minute

Mechanical & Protection

• Degree of protection: IP20

• Dimensions: W 45 mm H 100 mm D 81 mm

• Weight: 147 g
