About SIEMENS PLC MODULES 6ES7288-3AE04-0AA0

SIEMENS PLC MODULES 6ES7288-3AE04-0AA0 is a high-quality industrial Rack Mount module designed for efficient industrial automation processes. Weighing 147 grams and measuring 45 x 100 x 81 mm (L*W*H), this module is built to standard size specifications in a sleek grey color. With a service period of 12 months, it ensures long-term reliability and performance in diverse industrial settings.

Data Sheet 6ES7288-3AE04-0AA0

SIMATIC S7-200 SMART | Analog Input Module SM AI04
4 AI, 010 V / 05 V / 5 V / 2.5 V or 0/420 mA, 12-bit ADC

General Information

• Product type designation: SM AI04, AI 412 bit

• Configuration in RUN (CiR): No

• Reparameterization possible in RUN: No

Supply Voltage

• Type: DC

• Rated value: 24 V DC (-15% / +20%)

• Permissible range: 20.4 28.8 V DC

Input Current

• Typical: 40 mA

• From backplane bus 5 V DC: 80 mA

Power Loss

• Typical: 1.5 W

Analog Inputs

• Number of analog inputs: 4

Input Ranges

• Voltage: 10 V, 5 V, 2.5 V

• Current: 0 20 mA

• Thermocouple: No

• Resistance thermometer: No

• Resistance: No

Input Resistances

• -10 V +10 V: 9 M

• -5 V +5 V: 9 M

• -2.5 V +2.5 V: 9 M

• 0 20 mA: 250

Analog Value Generation

• Resolution (voltage): 11 bit + sign bit

• Resolution (current): 11 bit

• Interference voltage suppression: 10 / 50 / 60 / 400 Hz

• Smoothing (parameterizable, 4 stages): 1, 4, 16, 32 cycle time

Interrupts / Diagnostics / Status

• Diagnostics function: Yes

• Monitoring supply voltage: Yes

• Wire-break detection: No

• Short-circuit detection: No

• LED indication for input status: Yes

Protection

• Degree of protection: IP20

Mechanical Data

• Width: 45 mm

• Height: 100 mm

• Depth: 81 mm

• Weight: approx. 147 g
