Siemens S7-1200 1AO Expansion Module

About Siemens S7-1200 1AO Expansion Module

The Siemens S7-1200 1AO Expansion Module is designed to enhance the analog output (AO) capacity of Siemens S7-1200 PLCs by providing one additional analog output channel. This module is ideal for applications requiring precise control of actuators, variable speed drives, and proportional valves. Key Features: 1 Analog Output (AO) - Supports both voltage and current output signals High Precision & Resolution -Ensures accurate signal transmission Seamless PLC Integration -Compatible with Siemens S7-1200 controllers Compact & Space-Saving Design- Ideal for small control panels Reliable Industrial Performance - Designed for harsh automation environments Applications: Process Control & Automation Speed Control of Drives & Motors Proportional Valve & Actuator Control Industrial Sensor & Instrumentation Systems Naksh Technology Solution LLP is a trusted supplier of Siemens automation products, offering genuine and high-quality industrial solutions. For pricing and availability, contact Naksh Technology Solution LLP today!

SIMATIC S7-1200 Analog Output Module

Article No.: 6ES7232-4HA30-0XB0

Type: SB 1232, AQ 1x12 bit
Output: 1 AO, 10 V DC (12-bit) or 020 mA (11-bit)

General Information

• Product type designation: SB 1232, AQ 1x12 bit

• Backplane bus 5 V DC consumption: Typ. 15 mA

• Supply current for transmitters: Max. 25 mA

• Power loss: Typ. 1.5 W

Analog Outputs

• Number of outputs: 1

• Output ranges:

  • Voltage: -10 V to +10 V

  • Current: 020 mA

• Load impedance:

  • Voltage output: Min. 1,000

  • Current output: Max. 600

• Cable length (shielded, twisted pair): Max. 100 m

• Analog value generation: Differential

• Resolution: 12 bit (including sign)

Cycle Time

• Voltage output: 300 s (R), 750 s (1 F)

• Current output: 600 s (1 mH), 2 ms (10 mH)

Accuracy / Errors

• Temperature error: 0.5% at 25 C, 1% at 55 C

Diagnostics / Status

• Alarms: Yes

• Diagnostics function: Yes

• Output status LED: Yes

Standards / Approvals

• CE, CSA, UL, cULus, FM, RCM, KC, Marine approval: Yes

Ambient Conditions

• Operating temperature: -20 60 C (horizontal) / -20 50 C (vertical)

• Storage temperature: -40 70 C

• Air pressure (storage/transport): 6601,080 hPa

• Relative humidity: Max. 95% (at 25 C, no condensation)

• Pollutant concentrations: SO < 0.5 ppm, HS < 0.1 ppm (RH < 60%, condensation-free)

• Free fall: Max. 0.3 m, 5 times (packaged)

Mechanics / Dimensions

• Enclosure material: Plastic

• Width: 38 mm

• Height: 62 mm

• Depth: 21 mm

• Weight: 40 g
