Siemens S7-200 Smart 16do Module

About Siemens S7-200 Smart 16do Module

Product: Siemens S7-200 Smart 16DO Module

The Siemens S7-200 Smart 16DO Module is a digital output expansion module designed to increase the output capacity of S7-200 Smart PLCs. It provides enhanced control over industrial automation processes with a compact design for easy integration.

Key Features:

• 16 digital outputs for extended control and flexibility

• Fully compatible with Siemens S7-200 Smart PLCs

• Compact and space-saving design for easy installation

• Reliable and durable performance in industrial environments

• Easy configuration using STEP 7 Micro/WIN SMART software

Why Choose Naksh Technology?

• Authorized distributor of Siemens automation products

• 100% genuine products with manufacturer warranty

• Competitive pricing and bulk order discounts

• Expert technical support for seamless integration

Enhance your PLC system with the Siemens S7-200 Smart 16DO Module. Contact Naksh Technology for details and pricing.

SIMATIC S7-200 SMART Digital I/O Module SM DT32

Article No.: 6ES7288-2DT32-0AA0
Type: Digital I/O, 16 DI / 16 DO, 24 V DC, Transistor 0.75 A

General Information

• Product Type: SM DT32, DI 16x24 V DC, DQ 16x24 V DC / 0.75 A

Supply Voltage

• Rated Value: 24 V DC

• Permissible Range: 20.4 28.8 V DC

• Input Current from Backplane Bus 5 V DC: typ. 170 mA

Digital Inputs (DI)

• Number: 16 (in groups of 2)

• Parallel Switching: Yes

• Input Voltage:

  • Type: DC

  • Signal 0: < 5 V

  • Signal 1: +15 +30 V

• Input Current (Signal 1): 2.55 mA (typ. 4 mA)

• Input Delay: Max 200 s

• Cable Length:

  • Shielded: max. 500 m

  • Unshielded: max. 300 m

Digital Outputs (DO)

• Number: 16 (in groups of 3)

• Type: Current-sourcing, Transistor

• Short-Circuit Protection: No

• Switching Capacity:

  • Resistive Load: max. 0.75 A

  • Lamp Load: max. 5 W

• Output Voltage: 24 V DC

  • Signal 0: max 0.1 V

  • Signal 1: min 20 V, max 28.8 V

• Output Current: 0.75 A (per channel)

• Output Delay:

  • 0 1: max 50 s

  • 1 0: max 200 s

• Parallel Switching: Yes (only outputs of same group)

• Total Current per Group: max. 6 A (8 points), 3 A (4 points)

Diagnostics / Status

• LEDs for Input and Output Status: Yes

Potential Separation & Isolation

• Between Channels (DI / DO): Yes, Optocoupler

• Isolation Tested: 500 V AC / 1 min

EMC / Interference Immunity

• ESD (IEC 61000-4-2): 4 kV Contact, 8 kV Air

• HF Radiation (IEC 61000-4-3): Yes

• Burst (IEC 61000-4-4): 2 kV on supply lines, 2 kV on signal lines

• Surge (IEC 61000-4-5): Yes

• Conducted HF Disturbance (IEC 61000-4-6): 10 V/m, 80% AM at 1 kHz

• Emission: EN 55011, Class A, Group 1

Mechanical Data

• IP Degree of Protection: IP20

• Dimensions: W 70 mm H 100 mm D 81 mm

• Weight: 257.3 g
