Siemens S7-200 Smart 2AI RTD Module

Name: Siemens S7-200 Smart 2AI RTD Module
Brand: NAKSH TECHNOLOGY SOLUTION LLP
Price: 7500 INR
Availability: InStock

Price 7500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Siemens S7-200 Smart 2AI RTD Module Specification

Operating Temperature
-20 to +60 Celsius (oC)

Humidity %
95 %

Mounting Type
DIN Rail

Application
Automation

Protection Level
IP20

Frequency (MHz)
50/60 Hertz (HZ)

Rated Voltage
24 V DC Volt (V)

Energy Consumption
Electron-volt ( eV)

Dimension (L*W*H)
45 x 100 x 81 Millimeter (mm)

Weight
148.7 Grams (g)

Rated Current
40 Milliampere (mA)

Siemens S7-200 Smart 2AI RTD Module Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal, Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Days

Main Domestic Market
All India

Certifications
CE mark - Yes

About Siemens S7-200 Smart 2AI RTD Module

NAKSH TECHNOLOGY We are offering Siemens S7 200 Smart PLC MODULES to our client.SIMATIC S7-200 SMART PLC is designed to suit the needs of developing markets that have higher pressures of price and demands on performance. Providing an excellent performance-to-price ratio, SIMATIC S7-200 SMART PLC when combined with other SMART drive products from Siemens helps in building extremely cost effective efficient automation solutions.

Data sheet 6ES7288-3AR02-0AA0

SIMATIC S7-200 SMART, Analog input SM AR02 RTD, 2x AI RTD modules

General information

Product type designation: SM AR02, AI RTD 2x16 bit
CiR Configuration in RUN: Reparameterization possible in RUN: No

Supply voltage

Type of supply voltage: DC
Rated value (DC): 24 V; -15 / +20%

Input current

Current consumption, typ.: 40 mA
From backplane bus (5 V DC), typ.: 80 mA

Power loss

Power loss, typ.: 1.5 W

Analog inputs

Number of analog inputs: 2; Resistance thermometer
Permissible input voltage (destruction limit), max.: 30 V
Technical unit for temperature measurement adjustable: Yes; C / F

Input ranges

Voltage: No
Current: No
Thermocouple: No
Resistance thermometer: Yes; Pt10, Pt50, Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni200, Ni500, Ni1000, Cu10, Cu50, Cu100, LG-Ni1000
Resistance: Yes; 48 , 150 , 300 , 600 , 3 000

Input ranges (rated values), resistance thermometer

Type	Input resistance
Cu 10	10
Ni 100	100
Ni 1000	1 000
LG-Ni 1000	1 000
Ni 120	120
Ni 200	200
Ni 500	500
Pt 100	100
Pt 1000	1 000
Pt 200	200
Pt 500	500

Input ranges (rated values), resistors

0 to 48 , 0 to 150 , 0 to 300 , 0 to 600 , 0 to 3 000

Analog outputs

Number of analog outputs: 0

Analog value generation (inputs)

Measurement principle: Sigma Delta
Resolution with overrange (bit including sign), max.: 15 bit (for 150, 300, 600, 3 000 ); otherwise 15 bit + sign
Integration time (parameterizable): 10 / 16.67 / 20 / 100 ms
Interference voltage suppression (frequency f1): 10 / 50 / 60 / 400 Hz
