SIEMENS S7 400 - 6ES7414-2XL07-0AB0

About SIEMENS S7 400 - 6ES7414-2XL07-0AB0

Manufacturer SeriesS7 400Communication Protocols Profibus Mounting Type Rack Mount BRAND SIEMENS SIMATIC S7-400, CPU 414-2 Central processing unit with: Work memory 2 MB, (1 MB code, 1 MB data), 1st interface MPI/DP 12 Mbit/s, 2nd interface PROFIBUS DP.

Siemens SIMATIC S7-400 CPU 414-2

Part Number: 6ES7414-2XL07-0AB0

General Information

• Product Type: CPU 414-2

• HW Status: 01

• Firmware Version: V7.0

• Isochronous Mode: Yes (PROFIBUS only)

• Engineering Software: STEP 7 V5.4 or higher with HSP 261

Power Supply

• Via System Power Supply

• Backplane Bus Current:

  • 5 V DC: typ. 0.9 A, max. 1.1 A

  • 24 V DC: max. 300 mA (150 mA per DP interface)

• Interface 5 V DC: max. 90 mA per DP interface

• Power Loss: typ. 4.5 W

Memory

• Work Memory (RAM): 2 MB (1 MB code, 1 MB data)

• Expandable Memory:

  • FEPROM (with Memory Card) up to 64 MB

  • RAM (with Memory Card) up to 64 MB

• Backup: Yes, with battery (typ. 180 A, max. 850 A)

CPU Performance

• Bit/Word Operations: typ. 18.75 ns

• Fixed Point Arithmetic: typ. 18.75 ns

• Floating Point Arithmetic: typ. 37.5 ns

Program Blocks

• DBs: Max. 6,000, Size max. 64 kB

• FBs: Max. 3,000, Size max. 64 kB

• FCs: Max. 3,000, Size max. 64 kB

• OBs: Various types (cyclic, alarm, interrupt, error, startup)

Counters & Timers

• S7 Counters: 2,048, retentive adjustable

• IEC Counters: Unlimited (SFB)

• S7 Timers: 2,048, retentive adjustable

• IEC Timers: Unlimited (SFB)

Data Areas

• Flag Memory: 8 kB, retentive MB0MB15

• Local Data: adjustable up to 16 kB

• I/O Address Area: Inputs 8 kB, Outputs 8 kB

• Process Image: Inputs/Outputs adjustable 8 kB, consistent data max. 244 byte

• Digital Channels: Inputs/Outputs 65,536

• Analog Channels: Inputs/Outputs 4,096

Hardware Configuration

• Max Expansion Units: 21

• Connectable OPs: 63

• Multicomputing: Yes, up to 4 CPUs

• Interface Modules (IMs): Total max. 6, IM 460 max. 6, IM 463 max. 4

Interfaces

1. MPI/PROFIBUS DP:

   • Max connections: 32

   • Max baud rate: 12 Mbit/s

   • Supports PG/OP communication, routing, global data communication, S7 communication

2. PROFIBUS DP:

   • Max connections: 16

   • Max baud rate: 12 Mbit/s

   • Supports DPV1, Equidistance, Isochronous mode, Slave-to-slave communication

Communication

• S7 Routing: Yes

• S7 Basic Communication: Yes

• S7 Communication: Client/Server supported

• Standard Communication (FMS): Yes, via CP and loadable FB

• S5 Compatible Communication: Via FC AG_SEND/AG_RECV

Time & Clock

• Real-Time Clock: Yes, retentive and synchronizable

• Resolution: 1 ms

• Deviation per day: Max. 1.7 s (buffered), 8.6 s (unbuffered)

• Operating Hours Counter: 16, retentive

• Clock Synchronization: Supported via MPI, DP, AS

Programming

• Languages Supported: LAD, FBD, STL, SCL, CFC, GRAPH, HiGraph

• Simultaneously Active SFCs: Various (28 per interface)

• Simultaneously Active SFBs: 8 per interface

Security

• User Program Protection / Password Protection: Yes

• Block Encryption: Yes (S7 block privacy)

Physical Dimensions

• Width: 25 mm

• Height: 290 mm

• Depth: 219 mm

• Weight: ~700 g
