SIEMENS SIMATIC S7-200 SMART, Digital output EM DR16 16 DO, relay 2 A

Product: SIEMENS SIMATIC S7-200 SMART Digital Output EM DR16
Type: 16 DO Relay, 2 A
Material: High-quality PVC
Phase: Single-phase
Protection: Overheating protection, IP55
Warranty: 1 year

Designed for safe and durable operation, this digital output module delivers high-quality performance for industrial applications. Ideal for reliable functionality in various electrical and automation systems.

SIMATIC S7-200 SMART EM DR16

Article No.: 6ES7288-2QR16-0AA0
Digital Output Module 16 Relay Outputs (2 A each)

General Information

• Product designation: SM DR16, 16x Relay / 2 A

• Supply voltage: 24 V DC

• Permissible range: 20.428.8 V DC

• Current consumption:

  • Typical: 110 mA

  • From backplane bus (5 V DC): 165 mA

Digital Inputs

• Number of inputs: 0

Cable Length

• Shielded: max. 500 m

• Unshielded: max. 150 m

Digital Outputs

• Number of outputs: 16

• Grouping: 4 per group

• Type: Relay

• Short-circuit protection: No

• Switching capacity:

  • Resistive load: max. 2 A

  • Lamp load: 30 W DC / 200 W AC

• Output current:

  • Rated signal 1: 2 A

  • Max permissible: 2 A

• Output delay:

  • 0 1: 10 ms

  • 1 0: 10 ms

• Total current per group (horizontal up to 50C): max. 10 A

Relay Output Details

• Number of relay outputs: 16

• Relay coil voltage: 24 V DC

• Reverse polarity protection: Yes

• Relay coil total current: max. 150 mA

• Switching capacity:

  • Inductive load: max. 2 A

  • Lamp load: 30 W

  • Resistive load (up to 50C / 60C): max. 2 A

• Thermal continuous current: 2 A

Diagnostics / Indications

• LED indication for outputs: Yes

Isolation / Protection

• Potential separation: Yes (Relay dry contact)

• Isolation test:

  • Inputs: 500 V AC (1 min)

  • Outputs: 1500 V AC (1 min)

• Degree of protection: IP20

EMC (Electromagnetic Compatibility)

• ESD (IEC 61000-4-2): 4 kV contact, 8 kV air

• Radiated immunity (IEC 61000-4-3):

  • 10 V/m (801000 MHz)

  • 310 V/m (upper ranges)

• Burst (IEC 61000-4-4):

  • Supply: 2 kV

  • Signal cables: 2 kV

• Surge (IEC 61000-4-5): 2 kV asymmetric

• Conducted RF (IEC 61000-4-6): 10 V (150 kHz80 MHz)

• Emissions (EN 55011): Class A (Industrial)

Environmental Conditions

• Free fall: 0.3 m

• Operating temperature:

  • Horizontal: 055C

  • Vertical: 045C

• Storage/transport: 4070C

• Humidity: up to 95% (non-condensing)

Mechanical Data

• Width: 45 mm

• Height: 100 mm

• Depth: 81 mm

• Weight: approx. 220 g
