SIEMENS S7300-PLC-6ES7352-1AH02-0AE0

The SIEMENS S7300-PLC-6ES7352-1AH02-0AE0 is a high-performance automation controller designed for industrial applications. Featuring a sleek black design, the device is engineered for DIN-rail mounting, making it compact and efficient for space-constrained environments. Its protection level of IP20 ensures reliable operation in controlled settings, while its humidity tolerance of up to 95% makes it robust in challenging atmospheric conditions. Operating within a temperature range of 0 to 60C, this PLC supports seamless connectivity with its 1x 20-pin connection interface. Powered by a 24V DC input voltage, it consumes only 8.1 watts, offering energy-efficient performance. With an output current capacity of 600mA, its capable of handling high-precision industrial tasks. The unit weighs 550 grams and has dimensions of 80 x 125 x 120 mm, reflecting a well-engineered balance of portability and functionality. This versatile PLC functions at a frequency of 50/60 Hz, making it suitable for diverse automation setups.

Siemens 6ES7352-1AH02-0AE0 S7-300 Cam Controller (FM 352)

Electronic cam controller with configuration package on CD

Supply Voltage

• Rated Value (DC): 24 V

Input Current

• From load voltage L+ (no load): 200 mA max

• From backplane bus 5 V DC: 100 mA max

Encoder Supply

• 5 V Supply:

  • Output current max: 300 mA

  • Cable length max: 32 m

• 24 V Supply:

  • Output current max: 300 mA

  • Cable length max: 100 m

Power Loss

• Typical: 8.1 W

Digital Inputs

• Number of Inputs: 4

• Functions: Reference point switch, set floating actual value/length measurement, brake release, enable track output no. 3

• Rated Voltage: 24 V DC

• Signal "0": 30 to +5 V

• Signal "1": +11 to +30 V

• Input Current:

  • "0" max (quiescent): 2 mA

  • "1" typical: 9 mA

Digital Outputs

• Number of Outputs: 13

• Functions: Cam track

• Short-Circuit Protection: Yes

• Rated Voltage: 24 V DC

• Output Voltage "1" min: UP 0.8 V

• Output Current:

  • "1" permissible: 5 mA min, 600 mA max (060 C)

  • "0" residual current max: 0.5 mA

Encoder Compatibility

• Incremental Encoders (Symmetrical & Asymmetrical): Yes

• Absolute Encoder (SSI): Yes

• 2-Wire Sensors: Yes, max quiescent current 2 mA

Incremental Encoder (Symmetrical) Signals:

• Trace mark: A, notA, B, notB

• Zero mark: N, notN

• Input voltage: 5 V difference (RS 422)

• Max frequency: 1 MHz

Incremental Encoder (Asymmetrical) Signals:

• Trace mark: A, B

• Zero mark: N

• Input voltage: 24 V

• Max frequency: 50 kHz (25 m cable), 25 kHz (100 m cable)

Absolute Encoder (SSI) Signals:

• Data: DATA, notDATA

• Clock: CL, notCL

• Telegram length: 13 or 25 bit

• Clock frequency max: 1 MHz

• Gray code: Yes

• Max shielded cable length: 320 m at 125 kHz

Potential Separation

• Digital Inputs: No

• Digital Outputs: No

Ambient Conditions

• Operation Temperature: 0 C 60 C

• Storage/Transport: 40 C 70 C

Connection

• Required Front Connector: 1 20-pin

Dimensions

• Width: 80 mm

• Height: 125 mm

• Depth: 120 mm

Weight

• Approx.: 550 g

Technical Details
