SIEMENS SIMATIC S7-1500F CPU 1513F-1 PN

About SIEMENS SIMATIC S7-1500F CPU 1513F-1 PN

SIEMENS SIMATIC S7-1500F CPU 1513F-1 PNThe SIEMENS SIMATIC S7-1500F CPU 1513F-1 PN is a fail-safe programmable logic controller (PLC) designed for industrial automation applications. Its part of the SIMATIC S7-1500 series, which provides advanced control and safety functions.Key Features: - Fail-safe design: Ensures safe operation in critical applications- High-performance processing: Fast execution of complex control algorithms- Integrated safety functions: Supports advanced safety protocols- PROFINET communication: Fast and reliable communication with other devices- Compact design: Space-saving installation Technical Specifications: - CPU type: CPU 1513F-1 PN- Processing power: High-performance processing- Memory: Large program and data memory- Communication: PROFINET, PROFIBUS, and other protocols- Compatibility: SIMATIC S7-1500 systems- Certifications: SIL 3, PL e, and other safety certifications

SIMATIC S7-1500F, CPU 1513F-1 PN

Central processing unit with work memory 900 KB for program and 2.5 MB for data.1st interface: PROFINET IRT with 2-port switch, 6 ns bit performance.SIMATIC Memory Card required.

General Information

• Product type designation: CPU 1513F-1 PN

• HW functional status: FS04

• Firmware version: V4.0

• FW update possible: Yes

Product Function

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: Yes (Distributed min OB 6x = 500 s, Central = 1 ms)

• SysLog: Yes

Engineering

• STEP 7 TIA Portal: V20 (FW V4.0) / V18 (FW V3.0)

• Configurable with older versions as 6ES7 513-1FL02-0AB0

Configuration Control

• Via dataset: Yes

Display

• Screen diagonal: 3.45 cm

Control Elements

• Number of keys: 8

• Mode buttons: 2

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 19.2 V 28.8 V DC

• Reverse polarity protection: Yes

Mains Buffering

• Stored energy time: 5 ms

• Repeat rate min.: 1/s

Input Current

• Rated current consumption: 0.56 A

• Max current consumption: 0.9 A

• Inrush current max.: 1.15 A

• It: 0.6 As

Power

• Infeed power to backplane bus: 10 W

• Consumption from backplane bus: 5.5 W

• Typical power loss: 3.4 W

Memory

• SIMATIC Memory Card slots: 1

• Memory card required: Yes

Work Memory:

• Program: 900 KB

• Data: 2.5 MB

Load Memory:

• SIMATIC card up to 32 GB

Backup:

• Maintenance-free: Yes

CPU Processing Times

• Bit operations: 6 ns

• Word operations: 7 ns

• Fixed point arithmetic: 9 ns

• Floating point: 37 ns

CPU Blocks

• Elements total: 4000 (OB, FB, FC, DB, UDT)

DB:

• Number range: 160999

• Max size: 2.5 MB (64 KB for absolute addressing)

FB/FC:

• Number range: 065535

• Max size: 900 KB

OB:

• Max size: 900 KB

• Free cycle OBs: 100

Timers / Counters

• S7 counters: 2048

• S7 timers: 2048

• Retentivity adjustable: Yes

• IEC timers/counters: Limited only by memory

Data Areas

• Retentive data area max: 256 KB

• Extended retentive area: 2.5 MB (PS 60W HF required)

• Flags max: 16 KB

Address Area

• IO modules: 2048

• Inputs: 32 KB

• Outputs: 32 KB

Hardware Configuration

• Distributed IO systems: 32

• DP masters via CM: 6

• IO controllers: 1 integrated, up to 6 via CM

Time of Day

• Hardware clock backup: 6 weeks

• Max deviation: 10 s/day

Interfaces

• PROFINET interfaces: 1

• Ports: 2 (RJ45)

• Integrated switch: Yes

Protocols Supported

• IP, PROFINET IO Controller/Device

• SIMATIC communication

• Open IE communication

• Web server

• Media redundancy (MRP, MRPD)

PROFINET IO Controller

• Max IO devices: 128

• With IRT: 64

• Shared device support: Yes

PROFINET IO Device

• PROFIsafe: Yes (V2.4 / V2.6)

• 100 Mbps, Autonegotiation, Autocrossing: Yes

OPC UA

• Client & Server: Yes

• Sessions max: 32

• Max accessible variables: 50,000

• Security policies supported

MODBUS

• MODBUS TCP: Yes

Diagnostics

• Diagnostic buffer: 1000 entries (500 powerfail-proof)

• Trace: 4 traces, 512 KB each

Motion Control

• MC resources: 1120

• Axes depending on cycle time: 1114

Safety

• PL e (ISO 13849-1)

• SIL 3 (IEC 61508)

Environmental Conditions

• Operating temp (horizontal): -30C to 60C

• Vertical: -30C to 40C

• Storage: -40C to 70C

• Altitude: Up to 5000 m

Programming Languages

• LAD, FBD, STL, SCL, CFC, GRAPH

• All with safety support except where noted

Dimensions & Weight

• Width: 35 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: 336 g
