Siemens SIMATIC S7-1500F CPU 1516F-3 PN/DP (6ES7516-3FP03-0AB0)

General Information

• Product Type: CPU 1516F-3 PN/DP

• Hardware Status: FS04

• Firmware Version: V4.0 (FW update possible)

• I&M Data: Yes, I&M0 to I&M3

• Isochronous Mode: Yes (Distributed & Central)

• SysLog: Yes

• Engineering: STEP 7 TIA Portal V20+ (FW V4.0), older versions supported with limitations

Display & Control

• Screen Diagonal: 6.1 cm

• Keys: 8

• Mode Buttons: 2

Supply Voltage

• Rated: 24 V DC

• Range: 19.2 28.8 V DC

• Reverse Polarity Protection: Yes

• Mains Buffer: 5 ms

Current & Power

• Rated Current: 0.69 A

• Max Current: 1.08 A

• Inrush Current: 1.15 A

• Backplane Bus Power: 12 W

• Power Loss (typ.): 4 W

Memory

• Work Memory: 3 MB (Program), 7.5 MB (Data)

• Load Memory: Max. 32 GB (SIMATIC Memory Card)

• SIMATIC Memory Card Slot: 1

• Backup: Maintenance-free

CPU Performance

• Bit Operations: 6 ns

• Word Operations: 7 ns

• Fixed Point Arithmetic: 9 ns

• Floating Point Arithmetic: 37 ns

CPU Blocks

• Total Blocks (OB, FB, FC, DB, UDTs): 8,000

• DBs: 1 60,999 (Max 7.5 MB)

• FBs/FCs: 0 65,535 (Max 1 MB each)

• OB Size: Max 1 MB

• Free Cycle OBs: 100

Counters & Timers

• S7 Counters: 2,048

• IEC Counters: Unlimited (Main Memory)

• S7 Timers: 2,048

• IEC Timers: Unlimited (Main Memory)

• Retentive Memory: 512 KB (standard), 7.5 MB extended

I/O & Addressing

• Max I/O Modules: 8,192

• Inputs: 32 KB (per process image)

• Outputs: 32 KB (per process image)

• Subprocess Images: Max. 32

Hardware Configuration

• Distributed I/O Systems: Max. 64

• DP Masters: 1 integrated, max. 8 via CM

• IO Controllers: 2 integrated, max. 8 via CM

• Rack: Max. 32 modules

Clock & Synchronization

• Type: Hardware Clock

• Backup Time: 6 weeks at 40C

• Deviation: 2 s typical / 10 s max per day

• Clock Synchronization: DP, AS, NTP

Interfaces

1. PROFINET (X1) 2 ports, integrated switch

2. PROFINET (X2) 1 port, no switch

3. RS485 / PROFIBUS DP (X3) 1 port, Master only

Protocols & Services

• PROFINET IO Controller & Device, Isochronous Mode, IRT, PRO FIenergy, Web Server, Media Redundancy

• OPC UA Client & Server (runtime license required)

• TCP/IP, ISO-on-TCP, UDP, MODBUS TCP, SNMP, DCP, LLDP

Safety & Security

• Safety Level: PLe (ISO 13849-1), SIL 3 (IEC 61508)

• PROFINET Security Class: 1

• Secure Boot: Yes

• Signed Firmware Update: Yes

Supported Technology Objects

• Motion Control Resources: 2,400

• Positioning Axes: 11 (4 ms cycle), 20 (8 ms cycle)

• PID Controllers: Compact, 3-Step, Temperature

• High-Speed Counters: Yes

Ambient Conditions

• Operating Temperature: -30C to 60C (Horizontal), -30C to 40C (Vertical)

• Storage Temperature: -40C to 70C

• Max Installation Altitude: 5,000 m

Programming Languages

• LAD, FBD, STL, SCL, CFC, GRAPH

Protection & Access

• User Program Protection / Password: Yes

• Copy & Block Protection: Yes

• User Administration: Yes (Max. Users: 100, Groups: 100, Roles: 50)

Dimensions & Weight

• Width: 70 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: 469 g
