Siemens USB-MPI Cable 6GK1571-0BA00-0AA0

About Siemens USB-MPI Cable 6GK1571-0BA00-0AA0

Ensure seamless communication between your Siemens PLCs and PCs with the Siemens USB-MPI Cable 6GK1571-0BA00-0AA0. Designed for easy connection to Siemens PLCs, this USB-MPI cable offers reliable and fast communication for applications in industrial automation. The 6GK1571-0BA00-0AA0 model is specifically engineered to provide a simple, direct connection between the MPI (Multi-Point Interface) and your computers USB port, ensuring smooth data transfer and programming capabilities. The Siemens USB-MPI Cable 6GK1571-0BA00-0AA0 is compatible with a variety of Siemens PLC models, providing quick and efficient communication for diagnostics, configuration, and monitoring. Its plug-and-play functionality ensures ease of use and eliminates the need for complex setup processes. This cable is perfect for industrial environments where fast and reliable communication is key. At Naksh Technology Solution LLP, we provide expert support and seamless integration for the Siemens USB-MPI Cable 6GK1571-0BA00-0AA0, ensuring it meets the specific needs of your automation and control systems. Maximize your automation efficiency with the Siemens USB-MPI Cable 6GK1571-0BA00-0AA0, designed for smooth and reliable data exchange in your industrial operations.

Product Type Designation: PC adapter USB A2

PC adapter USB A2 USB adapter (USB V2.0) for connection of a PG/PC or notebook to SIMATIC S7 via PROFIBUS or MPI.Contains USB cable 5 m, MPI cable 0.3 m.Can be used under Windows XP / Vista / Windows 7 32/64 bit and higher.

Transfer Rate

• At the 1st interface / according to PROFIBUS: 9.6 kbit/s ... 12 Mbit/s

Interfaces

Number of electrical connections

• At the 1st interface / according to PROFIBUS: 1
• Number of interfaces / according to USB: 1

Type of electrical connection

• PROFIBUS: 9-pin Sub-D socket (RS 485)
• USB interface: Standard-B socket

USB Standard

• USB 2.0: Yes

Supply Voltage, Current Consumption, Power Loss

• Type of voltage / supply voltage: DC

• Optional external power supply: No

Supply voltage

• From USB: 5 V
• Note: Supply direct from USB

Relative symmetrical tolerance

• At 5 V: 5%

Consumed current

• From USB: 0.2 A

Power loss

• 1 W

Ambient Conditions

Ambient temperature

• During operation: 0 ... 60 °C
• During storage: -40 ... +70 °C
• During transport: -40 ... +70 °C
• Protection class IP: IP20
• Relative humidity at 30 °C, during operation, max: 95%

Design, Dimensions, Weight

• Module format: USB V2.0 adapter

• Width: 58 mm

• Height: 26 mm

• Depth: 105 mm

• Net weight: 0.365 kg

• Fastening method / 35 mm DIN-rail mounting: No
