SIEMENS V20 6SL3210-5BE21-5UV0 Drive System

The SIEMENS V20 6SL3210-5BE21-5UV0 is a high-efficiency automation solution (up to 98%) designed for demanding industrial applications.

Key Specifications:

• Rated Voltage: 380480V AC (3-phase)

• Power Rating: 1.50 kW

• Rated Current: 4.10 A

• Frequency Range: 4763 Hz

• Dimensions (L W H): 90 166 145.5 mm

• Weight: 1.00 kg

• Mounting: DIN rail

• Operating Temperature: -10C to +60C

• Humidity Tolerance: Up to 95%

• Protection Level: IP20

Features:

• Compact and lightweight for easy installation in space-limited setups

• Reliable performance with low energy consumption

• IP20 protection ensures durability in industrial environments

• Supports a wide range of operating conditions for versatility

This drive system is ideal for industrial automation, combining efficiency, reliability, and adaptability.

Data Sheet SINAMICS V20

Article No.: 6SL3210-5BE21-5UV0

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380 480 V (-15% / +10%)

• Line frequency: 47 63 Hz

Output

• Phases: 3 AC

• Rated voltage: 400 V (IEC) / 480 V (NEC)

• Rated power (LO): 1.50 kW / 2.00 hp

• Rated power (HO): 1.50 kW / 2.00 hp

• Rated current (LO): 4.10 A

• Rated current (HO): 4.10 A

• Rated current (IN): 4.10 A

• Pulse frequency: 4 kHz

• Output frequency: 0 550 Hz

Overload Capability

• Low Overload (LO): 110% for 60 s (cycle time 300 s)

• High Overload (HO): 150% for 60 s (cycle time 300 s)

General Technical Specifications

• Power factor : 0.72

• Cos : 0.95

• Efficiency : 0.98

• Integrated filter: Unfiltered

Communication

• USS, Modbus RTU

Inputs / Outputs

• Digital inputs: 4

• Digital outputs:

  • 1 relay (changeover)

  • 1 transistor

• Analog inputs: 2 (can be used as digital inputs)

• Analog outputs: 1

Ambient Conditions

• Cooling: External fan

• Installation altitude: Up to 1000 m

• Operating temperature: -10 60C

• Storage temperature: -40 70C

• Max. humidity: 95%

Connections

• Max. motor cable length:

  • Shielded: 10 m

  • Unshielded: 50 m

Mechanical Data

• Mounting: Wall / side-by-side

• Protection class: IP20 / UL open type

• Frame size: FSA

• Net weight: 1.0 kg

Dimensions

• Width: 90 mm

• Height: 166 mm

• Depth: 145.5 mm

Technical Details
