About SIEMENS VFD G120X 6SL3220-2YE20-0AF0

 SINAMICS G120X Rated power: 4 kW At 110% 60s, 100% 240 s Radio interference suppression filter for category C2 380-480 V 3 AC +10/-20% 47-63 Hz Ambient temperature -20 to +45 Degree C Size: FSB Degree of protection IP20 / UL open type painting 3C2 with Basic Operator Panel Without IO expansion Fieldbus integrated: PROFINET PN, Ethernet IP

SINAMICS G120X

Article No.: 6SL3220-2YE20-0AF0
Technical data are subject to change.

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380480 V (+10% / -20%)

• Line frequency: 4763 Hz

• Rated voltage: 400 V (IEC) / 480 V (NEC)

• Rated current:

  • LO: 9.75 A (IEC) / 8.00 A (NEC)

  • HO: 7.75 A (IEC) / 6.50 A (NEC)

Output

• Number of phases: 3 AC

• Rated voltage: 400 V (IEC) / 480 V (NEC)

• Rated power:

  • LO: 4.00 kW / 5.00 hp

  • HO: 3.00 kW / 4.00 hp

• Rated current:

  • LO: 10.20 A / 7.60 A

  • HO: 7.70 A / 6.20 A

  • IN: 10.50 A

• Max. output current: 14.00 A

• Pulse frequency: 4 kHz

• Output frequency:

  • Vector control: 0200 Hz

  • V/f control: 0550 Hz

Overload Capability

• LO: 110% base load for 60 s in 300 s cycle

• HO: 150% base load for 60 s in 600 s cycle

General Specifications

• Power factor : 0.700.85

• Cos : 0.96

• Efficiency : 0.97

• Sound pressure level (1 m): 63 dB

• Power loss: 0.142 kW

• Filter class: RFI suppression, Category C2

• EMC category: C2

• Safety function: Safe Torque Off without SIRIUS device

Communication

• PROFINET, EtherNet/IP

Inputs / Outputs

• Standard digital inputs: 6 (01: 11 V, 10: 5 V, max inrush 15 mA)

• Fail-safe digital inputs: 1

• Digital outputs: 2 (relay changeover contact, DC 30 V / 5 A)

• Analog/digital inputs: 2 (differential, 10-bit, 01: 4 V, 10: 1.6 V)

• Analog outputs: 1 (non-isolated)

• PTC/KTY interface: 1 motor temp. sensor (PTC, KTY, Thermo-Click, 5 C)

Closed-Loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with flux current control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless vector control: Yes

• Vector control with sensor: No

• Encoderless torque control: No

• Torque control with encoder: No

Ambient Conditions

• Standard board coating: Class 3C2 (IEC 60721-3-3)

• Cooling: Air, integrated fan

• Cooling air requirement: 0.005 m/s

• Installation altitude: 1,000 m

• Temperature:

  • Operation: -2045 C

  • Transport: -4070 C

  • Storage: -2555 C

• Relative humidity: Max 95% (no condensation/icing)

Connections

• Signal cable: 0.151.50 mm

• Line side: Screw terminals, 1.56 mm

• Motor end: Screw terminals, 1.56 mm

• PE connection: On housing, M4 screw

• Max. motor cable length: Shielded 150 m

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSB

• Net weight: 6.16 kg

• Dimensions (W H D): 100 275 218 mm
