About SIEMENS VFD G120X 6SL3220-2YE48-OUF0

Data Sheet SINAMICS G120X

Article No.: 6SL3220-2YE48-0UF0
Technical data subject to change

1. Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380480 V (+10% / -20%)

• Line frequency: 4763 Hz

• Rated voltage: 400 V IEC / 480 V NEC

• Rated current (LO): 241 A / 232 A

• Rated current (HO): 218 A / 191 A

Output

• Number of phases: 3 AC

• Rated voltage: 400 V IEC / 480 V NEC

• Rated power (LO): 132 kW / 200 hp

• Rated power (HO): 110 kW / 150 hp

• Rated current (LO): 250 A / 240 A

• Rated current (HO): 205 A / 180 A

• Rated current (IN): 256 A

• Max. output current: 338 A

• Pulse frequency: 2 kHz

• Output frequency (vector control): 0200 Hz

• Output frequency (V/f control): 0550 Hz

Overload Capability

• Low Overload (LO): 110% IL for 60 s in 300 s

• High Overload (HO): 150% IH for 60 s in 600 s

2. General Technical Specifications

• Power factor : 0.900.95

• Cos : 0.99

• Efficiency : 0.98

• Sound pressure level: 72 dB (1 m)

• Power loss (typical): 3.160 kW

• Integrated filter class: Unfiltered

• EMC category: Without accessories

• STO safety: Not available (without SIRIUS)

3. Communication

• Interfaces: PROFINET, EtherNet/IP

4. Inputs / Outputs

Digital Inputs

• Quantity: 6

• Switching level (01): 11 V

• Switching level (10): 5 V

• Max inrush: 15 mA

Fail-Safe Digital Inputs

• Quantity: 1

Digital Outputs

• Relay changeover contacts: 2 (DC 30V, 5A)

• Transistor outputs: 0

Analog/Digital Inputs

• Quantity: 2 (Differential)

• Resolution: 10 bit

• Switching thresholds:

  • 01: 4 V

  • 10: 1.6 V

Analog Outputs

• Quantity: 1 (Non-isolated)

Motor Temperature Sensor Input

• Sensors: PTC, KTY, Thermo-Click

• Accuracy: 5C

5. Control Functions

• V/f linear / square-law / parameterizable: Yes

• V/f with FCC: Yes

• V/f ECO: Yes

• Sensorless vector control: Yes

• Vector control with sensor: No

• Encoderless torque control: No

• Torque control with encoder: No

6. Ambient Conditions

• Board coating: Class 3C2 (IEC 60721-3-3)

• Cooling: Air cooling (integrated fan)

• Air requirement: 0.153 m/s

• Installation altitude: 1,000 m

Temperatures

• Operation: 20 to 45C

• Transport: 40 to 70C

• Storage: 25 to 55C

Humidity

• Max. 95% (no condensation / icing)

7. Connections

Signal Cable

• Conductor size: 0.151.50 mm (AWG 2416)

Line Side

• Connection: M10 screw

• Conductor size: 352120 mm (AWG 1 to 24/0)

Motor End

• Connection: M10 screw

• Same conductor size as above

DC Link / PE

• PE connection: M10 screw

Max Motor Cable Length

• Shielded: 300 m

• Unshielded: 450 m

8. Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSF

• Weight: 67 kg

Dimensions

• Width: 305 mm

• Height: 709 mm

• Depth: 369 mm

9. Standards & Efficiency

• Approvals: UL, cUL, CE, RCM, EAC, KCC, SEMI F47, REACH

• Efficiency class: IE2 (IEC 61800-9-2)

Basic Operator Panel (BOP-2)

Display

• LCD, monochrome

Mechanical

• Protection: IP55 / UL Type 12

• Weight: 0.140 kg

Dimensions

• Width: 70 mm

• Height: 106.85 mm

• Depth: 19.6 mm
