About SIEMENS VFD G120X 6SL3220-3YE10-0UF0

SINAMICS G120X

Article No.: 6SL3220-3YE10-0UF0
Compact AC Drive 3-phase input/output

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380480 V (+10% / 20%)

• Line frequency: 4763 Hz

• Rated current (LO): 2.10 A (IEC 400V), 2.00 A (NEC 480V)

• Rated current (HO): 1.70 A (IEC 400V), 1.60 A (NEC 480V)

Output

• Phases: 3 AC

• Rated voltage: 400V (IEC), 480V (NEC)

• Rated power:

  • LO: 0.75 kW (1.00 hp)

  • HO: 0.55 kW (0.75 hp)

• Rated current:

  • LO: 2.20 A (IEC), 2.10 A (NEC)

  • HO: 1.70 A (IEC), 1.60 A (NEC)

  • IN: 2.30 A

• Max. output current: 2.70 A

• Pulse frequency: 4 kHz

• Output frequency:

  • Vector control: 0200 Hz

  • V/f control: 0550 Hz

Overload Capability

• Low Overload (LO): 110% base load for 60 s in 300 s cycle

• High Overload (HO): 150% base load for 60 s in 600 s cycle

General Technical Specifications

• Power factor : 0.700.85

• Power factor cos : 0.96

• Efficiency : 0.96

• Sound pressure level (1 m): 55 dB

• Power loss (typical): 0.043 kW

• Filter class: Unfiltered

• EMC category: None (without accessories)

• Safety function: Safe Torque Off without SIRIUS device (via S7-1500F)

Communication

• PROFINET, EtherNet/IP

Inputs / Outputs

• Standard digital inputs: 6

  • Switching levels: 0 1 = 11 V, 1 0 = 5 V

  • Max inrush current: 15 mA

• Fail-safe digital inputs: 1

• Digital outputs (relay): 2 (DC 30 V, 5 A)

• Transistor outputs: 0

• Analog/differential inputs: 2 (10-bit resolution)

  • Switching threshold: 0 1 = 4 V, 1 0 = 1.6 V

• Analog outputs: 1 (non-isolated)

• PTC/KTY interface: 1 motor temperature sensor input (PTC, KTY, Thermo-Click), accuracy 5 C

Closed-Loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with flux current control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless vector control: Yes

• Vector control with sensor: No

• Encoderless torque control: No

• Torque control with encoder: No

Ambient Conditions

• Standard board coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air cooling with integrated fan

• Cooling air requirement: 0.005 m/s

• Installation altitude: 1,000 m

• Ambient temperature:

  • Operation: 2045 C

  • Transport: 4070 C

  • Storage: 2555 C

• Relative humidity: Max 95% at 40 C, no condensation or icing

Connections

• Signal cable: 0.151.50 mm

• Line side: Screw-type terminal, 1.52.5 mm

• Motor end: Screw-type terminal, 1.52.5 mm

• DC link (for braking resistor) / PE: On housing with M4 screw

• Max. motor cable length:

  • Shielded: 150 m

  • Unshielded: 300 m

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSA

• Net weight: 3.2 kg

• Dimensions (W H D): 73 232 218 mm
