About SIEMENS ATV310H037N4E, Variable Speed Drive

Looking for aSchneider Electric Altivar ATV310H037N4E Variable Speed Drivefor your industrial applications? Naksh Technology Solution LLP offers theATV310H037N4E, a reliable and efficient0.37 kW (0.5 HP) Variable Frequency Drive (VFD)designed forthree-phase 380-460V AC motors.

Key Features

• Power rating: 0.37 kW / 0.5 HP
• Input voltage: 3-phase 380-460V AC
• Compact and robust designfor industrial environments
• Easy setup and user-friendly interface
• High-performance motor controlfor pumps, fans, conveyors, and machines
• Built-in protection featuresto ensure reliability and safety

• Industrial automation
• HVAC systems
• Pumps and fans
• Conveyor systems
• General-purpose motor control

Enhance your motor control system with the Schneider Electric ATV310H037N4E Variable Speed Drive. Contact Naksh Technology Solution LLP today for the best offers

Data Sheet: SINAMICS G120XA

Article No.: 6SL3220-3YD44-0CB0
Technical data are subject to change! There may be discrepancies between calculated and rating plate values.

General Information

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380 ... 440 V +10 % -20 %

• Line frequency: 47 ... 63 Hz

• Rated current (LO): 164.00 A

Output

• Number of phases: 3 AC

• Rated voltage: 400 V

• Rated power IEC 400V (LO): 90.00 kW

• Rated current 400V (IN): 164.00 A

• Rated current 380V (IN): 174.00 A

• Rated current (LO): 164.00 A

• Max. output current: 181.00 A

• Pulse frequency: 4 kHz

• Output frequency for vector control: 0 ... 240 Hz

• Output frequency for V/f control: 0 ... 550 Hz

Overload Capability

• Low Overload (LO): 110% base load current IL for 60 s in a 600 s cycle time

• Max. output current: Max. output current for 60 s in a 600 s cycle time

General Tech. Specifications

• Power factor : 0.75 ... 0.93

• Power factor cos : 1 0.99

• Efficiency : 0.98

• Sound pressure level (1m): 73.1 dB

• Power loss: 2.180 kW

• Filter class (integrated): RFI suppression filter for Category C3

• EMC category (with accessories): Category C3

• Safety function "Safe Torque Off": without SIRIUS device (e.g., via S7-1500F)

Communication

• Communication: USS, Modbus RTU, BACnet MS/TP

Inputs / Outputs

Standard Digital Inputs

• Number: 6

• Switching level: 0 1: 11 V, 1 0: 5 V

• Max. inrush current: 15 mA

Fail-safe Digital Inputs

• Number: 0

Digital Outputs

• Number as relay changeover contact: 4

• Output (resistive load): DC 30 V, 1.0 A

• Number as transistor: 0

Analog / Digital Inputs

• Number: 2 (Differential input)

• Resolution: 12 bit

• Switching threshold as digital input: 0 1: 4 V, 1 0: 1.6 V

Analog Outputs

• Number: 2 (Non-isolated output)

PTC / KTY Interface

• 1 motor temperature sensor input, sensors that can be connected: PTC, KTY, PT1000 and Thermo-Click, accuracy 5 C

Closed-loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with flux current control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless vector control: Yes

• Vector control, with sensor: No

• Encoderless torque control: Yes

• Torque control, with encoder: No

Ambient Conditions

• Standard board coating type: Class 3C2, according to IEC 60721-3-3:2002

• Cooling: Air cooling using an integrated fan

• Cooling air requirement: 0.153 m/s (5.403 ft/s)

• Installation altitude: 1,000 m (3,280.84 ft)

Ambient Temperature

• Operation: -20 ... 60 C (-4 ... 140 F)

• Transport / Storage: -40 ... 70 C (-40 ... 158 F)

Relative Humidity

• Max. operation 95 % at 40 C (104 F), condensation and icing not permissible

Connections

• Signal cable: Conductor cross-section 0.15 ... 1.50 mm (AWG 24 ... AWG 16)

• Line side: Version M10 screw; Conductor cross-section 35.00 ... 2 x 120.00 mm (AWG 1 ... AWG 2 x 4/0)

• Motor end: Version M10 screw; Conductor cross-section 35.00 ... 2 x 120.00 mm (AWG 1 ... AWG 2 x 4/0)

• DC link (for braking resistor): PE connection M10 screw

• Max. motor cable length (shielded): 150 m (492.13 ft)

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSF

• Net weight: 66.8 kg (147.27 lb)

Dimensions

• Width: 305 mm (12.01 in)

• Height: 709 mm (27.91 in)

• Depth: 360 mm (14.17 in)

Standards

• Compliance with standards: CE, EAC, RCM, RoHS II

• CE marking: EMC Directive 2004/108/EC, Low-Voltage Directive 2006/95/EC

• Converter losses to IEC61800-9-2*

  • Efficiency class: IE2

  • Comparison with reference converter (90% / 100%): 46.7 %

  • Percentage values show losses in relation to rated apparent power of the converter.

Operator Panel: Intelligent Operator Panel (IOP-2)

Screen

• Display design: LCD color

• Screen resolution: 320 x 240 Pixel

Mechanical Data

• Degree of protection: IP55 / UL type 12

• Net weight: 0.134 kg (0.30 lb)

• Dimensions:

  • Width: 70.00 mm (2.76 in)

  • Height: 106.85 mm (4.21 in)

  • Depth: 19.65 mm (0.77 in)

Technical Details
