About SIEMENS VFD G120XA 6SL3220-2YD46-OUB0

The SIEMENS VFD G120XA 6SL3220-2YD46-OUB0 is a top-of-the-line Variable Frequency Drive (VFD) designed for industrial applications. With a robust IP20 protection level, it ensures reliable performance in various working environments. Operating at a frequency of 47-63 Hz, it offers precise control over motor speed for enhanced efficiency. The warranty of 1 year provides peace of mind to users. Constructed with high-quality PVC material and finished with a durable powder coating in black, this VFD is built to last. Its digital display makes monitoring and adjusting settings convenient. The compact dimensions of 305 x 709 x 360 mm make it suitable for space-constrained installations. Rated at 380-480 V, this VFD is a reliable solution for industrial power management needs.

SINAMICS G120XA

Article No.: 6SL3220-2YD46-0UB0

Rated Data

Input:

• Phases: 3 AC

• Line Voltage: 380 440 V (+10% / -20%)

• Line Frequency: 47 63 Hz

• Rated Current (LO): 200 A

Output:

• Phases: 3 AC

• Rated Voltage: 400 V

• Rated Power IEC 400V (LO): 110 kW

• Rated Current 400V (IN): 201 A

• Rated Current 380V (IN): 205 A

• Rated Current (LO): 201 A

• Max. Output Current: 222 A

• Pulse Frequency: 2 kHz

• Output Frequency Vector Control: 0 240 Hz

• Output Frequency V/f Control: 0 550 Hz

Overload Capability

• Low Overload (LO): 110% for 60 s (600 s cycle)

General Technical Specifications

• Power Factor : 0.75 0.93

• Power Factor cos : 0.99

• Efficiency : 0.98

• Sound Pressure Level (1 m): 73.1 dB

• Power Loss: 2.27 kW

• Filter Class: Unfiltered

• EMC Category: Without

• Safety Function: Safe Torque Off (without SIRIUS device)

Communication

• USS, Modbus RTU, BACnet MS/TP

Inputs / Outputs

• Standard Digital Inputs: 6 (01: 11 V, 10: 5 V, Max inrush 15 mA)

• Fail-safe Digital Inputs: 0

• Digital Outputs: 4 relay contacts (DC 30 V, 1 A)

• Analog / Digital Inputs: 2 differential, 12-bit (01: 4 V, 10: 1.6 V)

• Analog Outputs: 2 (non-isolated)

• Motor Temperature Sensor Input: 1 (PTC, KTY, PT1000, Thermo-Click, 5 C)

Closed-loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with Flux Current Control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless Vector Control: Yes

• Vector Control with Sensor: No

• Encoderless Torque Control: Yes

• Torque Control with Encoder: No

Ambient Conditions

• Board Coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air cooling with integrated fan

• Cooling Air Requirement: 0.153 m/s

• Installation Altitude: 1,000 m

• Operation Temp: -20 60 C

• Transport Temp: -40 70 C

• Storage Temp: -40 70 C

• Max Relative Humidity: 95% (no condensation or icing)

Connections

• Signal Cable: 0.15 1.50 mm (AWG 24 16)

• Line Side: M10 screw, 35 2 120 mm (AWG 1 2 4/0)

• Motor End: M10 screw, 35 2 120 mm (AWG 1 2 4/0)

• DC Link / PE Connection: M10 screw

• Max Motor Cable Length: Shielded 300 m, Unshielded 450 m

Mechanical Data

• Degree of Protection: IP20 / UL open type

• Frame Size: FSF

• Net Weight: 64 kg

• Dimensions (W H D): 305 709 360 mm

Standards

• Compliance: CE, EAC, RCM, RoHS II

• CE Marking: EMC Directive 2004/108/EC, Low-Voltage Directive 2006/95/EC

Converter Losses (IEC61800-9-2)

• Efficiency Class: IE2

• Loss Comparison (90% / 100%): 39.8%

• Typical Losses: 591 2,270 W depending on load

Operator Panel: Basic Operator Panel (BOP-2)

• Display: LCD, monochrome

• Degree of Protection: IP55 / UL type 12

• Net Weight: 0.14 kg

• Dimensions (W H D): 70 106.85 19.6 mm

• Ambient Temp Operation: 0 50 C

• Storage / Transport: -40 70 C

• Max Relative Humidity: 95%

• Approvals: CE, cULus, EAC, KCC, RCM
