About SIEMENS VFD G120XA 6SL3220-3YD58-0CB0

Data Sheet SINAMICS G120XA

Article No.: 6SL3220-3YD58-0CB0

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380 440 V (+10% / -15%)

• Line frequency: 47 63 Hz

• Rated current (LO): 684 A

Output

• Phases: 3 AC

• Rated voltage: 400 V

• Rated power (IEC, 400 V, LO): 355 kW

• Rated current:

  • 400 V (IN): 643.87 A

  • 380 V (IN): 670 A

  • LO: 620 A

• Max. output current: 870 A

• Pulse frequency: 2 kHz

• Output frequency (V/F & vector): 0 100 Hz

Overload Capability

• LO: 110% of base load current (60 s / 600 s cycle)

• Max. output current: for 60 s / 600 s cycle

General Technical Specifications

• Power factor (): 0.75 0.93

• Power factor cos 1: 0.99

• Efficiency: 0.98

• Sound level (1 m): 72.9 dB

• Power loss (typical): 7.7 kW

• Integrated filter: RFI Category C3

• EMC category (with accessories): C3

• STO (Safe Torque Off): Supported (without SIRIUS devices)

Communication

• USS

• Modbus RTU

• BACnet MS/TP

Inputs / Outputs

Digital Inputs

• Number: 6

• Switching levels:

  • 0 1: 11 V

  • 1 0: 5 V

• Max. inrush current: 15 mA

Fail-safe Inputs

• 0

Digital Outputs

• Relay outputs: 4 (changeover)

• Resistive load: 30 V DC, 1 A

Analog/Digital Inputs

• Number: 2 (differential)

• Resolution: 12 bit

• DI switching thresholds:

  • 0 1: 4 V

  • 1 0: 1.6 V

Analog Outputs

• Number: 2 (non-isolated)

PTC/KTY Sensor Input

• Supported sensors: PTC, KTY, PT1000, Thermo-Click

• Accuracy: 5 C

Control Functions

• V/f (linear / square-law / parameterizable)

• V/f with FCC

• V/f ECO (linear / square-law)

• Sensorless vector control

• Encoderless torque control

• No encoder-based vector control

Ambient Conditions

• Board coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air cooling with integrated fan

• Airflow: 0.345 m/s

• Installation altitude: 1,000 m

• Operating temperature: 0 60 C

• Storage: -25 55 C

• Transport: -40 70 C

• Max. humidity: 95% (no condensation/icing)

Connections

Signal Cable

• Conductor size: 0.15 1.5 mm (AWG 24 16)

Line Side

• Type: M12 screw

• Cable size: 2 240 mm (MCM 2 500)

Motor Side

• Type: M12 screw

• Cable size: 4 240 mm (MCM 2 500)

DC Link / PE

• PE: M12 screw

Max. Motor Cable Length

• Shielded: 100 m

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSH

• Weight: 134 kg

• Dimensions:

  • Width: 548 mm

  • Height: 1,487 mm

  • Depth: 410 mm

Standards & Approvals

• CE, EAC, RCM, RoHS II

• CE (EMC Directive 2004/108/EC, LVD 2006/95/EC)

Converter Losses (IEC 61800-9-2) Efficiency Class IE2

• At 90% torque: 2,780 W (0.6%)

• At 50% torque: 1,820 W (0.4%)

• At 25% torque: 1,970 W (0.4%)

• At 100% torque: 5,940 W (1.3%)

• Max losses: 7,700 W (1.7%)

Operator Panel IOP-2

Display

• LCD color, 320 240 px

Mechanical

• IP55 / UL Type 12

• Weight: 0.134 kg

• Dimensions: 70 106.85 19.65 mm

Environment

• Operating temp: 0 50 C (55 C with door kit)

• Storage & transport: -40 70 C

• Humidity: 95% max
