About SIMATIC HMI MTP1500, 6AV2128-3QB06-0AX1

The Siemens SIMATIC HMI MTP1500 (6AV2128-3QB06-0AX1)is a15.6-inch high-performance multi-touch panel designed for industrial automation and machine control applications. It offers an intuitive interface for monitoring, visualization, and operation of industrial processes, ensuring high efficiency and precision.

Key Features:

• 15.6-inch high-resolution multi-touch display for enhanced usability
• Supports PROFINET and Ethernet communication for seamless system integration
• Fast response time for real-time process control
• Rugged industrial-grade design for long-term reliability in demanding environments
• Fully compatible with TIA Portal for easy configuration and programming

Applications:

• Industrial automation and process monitoring
• Machine operation and control systems
• Packaging and material handling solutions
• Factory automation and production line management

For more details and pricing,contact Naksh Technology Solution LLP today

Data Sheet 6AV2128-3QB06-0AX1

SIMATIC HMI MTP1500 Unified Comfort Panel

15.6" widescreen TFT display, 16 million colors, touch operation, PROFINET interface. Configurable as of WinCC Unified Comfort V16. Includes open-source software (see enclosed DVD).

General Information

• Product type designation: MTP1500 Unified Comfort

Display

• Type: TFT

• Screen size: 15.6 in

• Display width: 344.2 mm

• Display height: 197 mm

• Colors: 16,777,216

• Resolution: 1366 768 pixels

• Backlight MTBF: 50,000 h

• Backlight dimming: Yes (10100%)

Control Elements

• Numeric keyboard: Yes (On-screen)

• Alphanumeric keyboard: Yes (On-screen)

• Touch screen: Yes

• Multi-touch: Yes

Installation / Mounting

• Mounting position: Vertical

• Portrait format possible: Yes

• Landscape format possible: Yes

• Max tilt angle without external ventilation: 35

Supply Voltage

• Type: DC

• Rated value: 24 V

• Range: 19.2 28.8 V

Input Current

• Rated consumption: 0.7 A

• Max consumption: 1.3 A

• Inrush current It: 0.5 As

Memory

• Flash: Yes

• RAM: Yes

Acoustics

• Buzzer: Yes

• Speaker: No

Time of Day

• Real-time hardware clock: Yes

• Software clock: Yes

• Retentive: Yes (approx. 6 weeks backup)

• Synchronizable: Yes

Interfaces

• Industrial Ethernet: 2 (switch ports + independent port)

• RS485: 1 (RS422/485 combined)

• USB: 4 USB 3.1 Gen 1 (Type A)

• SD card slots: 2

Industrial Ethernet

• Status LEDs: 2

• Switch ports: 2

Protocols

• PROFINET: Yes

• PROFINET IO: No

• TCP/IP, DHCP, SNMP, DCP, LLDP: Yes

• Media redundancy (MRP): Yes

EMC

• EN 55011 Class A (industrial): Yes

• EN 55011 Class B (residential): No

Protection Class

• Front: IP65

• Rear: IP20

• NEMA: Type 4X (front), Type 12 (front)

Approvals

CE, UKCA, cULus, RCM, KC, EAC, CCC

Environmental Footprint (CO eq)

• Total: 272.6 kg

• Production: 74.9 kg

• Operation: 211 kg

• End of life: -13.3 kg

Use in Hazardous Areas

• ATEX Zone 2, 22: Yes

• IECEx Zone 2, 22: Yes

• cULus / FM Class I & II Division 2: Yes

Marine Approvals

ABS, BV, DNV, KRS, LRS, Class NK, CCS

Ambient Conditions

• Indoor use: Yes

• Outdoor use: No

Operating Temperature

• Vertical: 0 to 50C

• Max tilt angle: 0 to 40C

• Portrait: 0 to 40C

• Tilted portrait: 0 to 35C

Storage Temperature

• -20 to 60C

• Humidity: Max 90% (no condensation)

Operating System

• Proprietary

Functions

• Message indicator

• Alarm system

• Process value display

• Recipe management

Configuration Software

• WinCC Unified Comfort Engineering (TIA Portal)

• WinCC Unified PC Engineering (TIA Portal)

Languages

• Online languages: 32

• Project languages: 32

WinCC Unified Functionality

Includes:
Libraries, Writer, Web Browser, Media Player, Sm@rtServer, WinCC Audit, Unified Collaboration, JavaScript, Task Planner.

Alarm System

• Alarm classes: 32

• Bit messages: 9,000

• Analog messages: 300

• Message buffer: Retentive, circular

• Characters per message: 512

Recipes

• Types: 750

• Sets per type: 2000

• Entries per set: 1000

• Internal memory: 12 MB

• Expandable: Yes

Variables

• Per device: 8,000

• Per screen: 800

• Supports: Limits, Structures, Arrays

Screens

• Configurable images: 1,200

• Objects per image: 1,200

• Complex objects per screen: 80

• Supports: Faceplates, Trend view, User view, Bar graphs, Sliders, SVG, etc.

Archiving

• Archives per device: 50

• Entries per archive: 500,000

• Types: Sequential, Short-term

• Storage: SD card, USB

• Ethernet storage: No

Security

• Roles: 50

• Users: 200

• Function rights: 20

• Password import/export: Yes

• Central user administration: Yes (WinCC V17+)

Transfer

• Ethernet: Yes

• USB: No

• External media: Yes (V17+)

Process Coupling

• Supports S7-1200, S7-1500, S7-300/400, LOGO!, OPC UA (Client & Server)

Service Tools

Backup/Restore (manual & automatic), Simulation, Device switchover.

Peripherals

Printers, barcode readers, SD cards, USB memory.

Mechanics / Dimensions

• Front material: Aluminum

• Front width: 398 mm

• Front height: 257 mm

• Cutout: 382 241 mm

• Depth: 73 mm

• Weight: 4.3 kg
