Datasheet SINAMICS G120C

Article No.: 6SL3210-1KE12-3UB2

Rated Data

Input

• Phases: 3 AC

• Line Voltage: 380 480 V (+10% / 20%)

• Line Frequency: 47 63 Hz

• Rated Current (LO): 2.90 A

• Rated Current (HO): 2.50 A

Output

• Phases: 3 AC

• Rated Voltage: 400 V IEC / 480 V NEC

• Rated Power (LO): 0.75 kW / 1.00 hp

• Rated Power (HO): 0.55 kW / 0.75 hp

• Rated Current (LO): 2.20 A

• Rated Current (HO): 1.70 A

• Rated Current (IN): 2.30 A

• Max. Output Current: 3.40 A

• Pulse Frequency: 4 kHz

• Output Frequency (Vector Control): 0 240 Hz

• Output Frequency (V/f Control): 0 550 Hz

Overload Capability

Low Overload (LO)

• 150% IL for 3 s

• then 110% IL for 57 s (within 300 s cycle)

High Overload (HO)

• 200% IH for 3 s

• then 150% IH for 57 s (within 300 s cycle)

General Technical Specifications

• Power Factor (): 0.70 0.85

• Cos : 0.95

• Efficiency (): 0.97

• Sound Pressure Level (1 m): 49 dB

• Power Loss: 38.6 W

• Integrated Filter: Unfiltered

• Communication: USS / MODBUS RTU

Inputs / Outputs

Standard Digital Inputs

• Quantity: 6

• Switching Level (01): 11 V

• Switching Level (10): 5 V

• Max Inrush Current: 15 mA

Fail-safe Digital Inputs

• Quantity: 1

Digital Outputs

• Relay Output: 1 (DC 30 V, 0.5 A)

• Transistor Output: 1 (DC 30 V, 0.5 A)

Analog / Digital Input

• Quantity: 1 (Differential)

• Resolution: 10 bit

• Digital Switching Threshold:

  • 01: 4 V

  • 10: 1.6 V

Analog Output

• Quantity: 1 (Non-isolated)

Motor Temperature Sensor Input

• Supports PTC, KTY, Thermo-Click

• Accuracy: 5C

Control Functions

• V/f (linear, square-law, parameterizable) Yes

• V/f ECO Yes

• Flux Current Control (FCC) Yes

• Sensorless Vector Control Yes

• Vector Control with Sensor No

• Encoderless Torque Control No

• Torque Control with Encoder No

Ambient Conditions

• Cooling: Integrated fan

• Cooling Air Requirement: 0.005 m/s

• Installation Altitude: 1000 m max

• Operating Temp.: 10 40C

• Transport Temp.: 40 70C

• Storage Temp.: 25 55C

• Humidity: Max 95% (no condensation/icing)

Connections

Signal Cable

• 0.15 1.50 mm (AWG 24 16)

Line Side

• Plug-in screw terminals

• 1.00 2.50 mm (AWG 18 14)

Motor End

• Plug-in screw terminals

• 1.00 2.50 mm (AWG 18 14)

DC Link (Braking Resistor)

• Plug-in screw terminals

• 1.00 2.50 mm (AWG 18 14)

Other

• Max line length: 15 m

• PE Connection: M4 screw

• Max Motor Cable Length:

  • Shielded: 150 m

  • Unshielded: 150 m

Mechanical Data

• Protection Class: IP20 / UL open type

• Frame Size: FSAA

• Net Weight: 1.40 kg

• Dimensions:

  • Width: 73 mm

  • Height: 173 mm

  • Depth: 155 mm
