About SIMATIC HMI MTP1900, 6AV2128-3UB06-0AX1

The Siemens SIMATIC HMI MTP1900 (6AV2128-3UB06-0AX1)is a19-inch high-performance multi-touch panel designed for industrial automation and machine control applications. It offers an intuitive interface for monitoring, visualization, and operation of industrial processes, ensuring high efficiency and precision.

Key Features:

• 19-inch high-resolution multi-touch display for enhanced usability
• Supports PROFINET and Ethernet communication for seamless system integration
• Fast response time for real-time process control
• Durable industrial-grade design for long-term reliability in harsh environments
• Fully compatible with TIA Portal for easy configuration and programming

Applications:

• Industrial automation and process monitoring
• Machine operation and control systems
• Packaging and material handling solutions
• Factory automation and large-scale production line management

For more details and pricing,contact Naksh Technology Solution LLP today

Data Sheet: 6AV2128-3UB06-0AX1

SIMATIC HMI MTP1900 Unified Comfort Panel
18.5" widescreen TFT display, 16M colors, PROFINET, configurable from WinCC Unified Comfort V16.

General Information

• Product type designation: MTP1900 Unified Comfort

Display

• Display type: TFT

• Screen size: 18.5 in

• Display width: 408.96 mm

• Display height: 230.04 mm

• Colors: 16,777,216

• Resolution: 1920 1080 pixels

• Backlight MTBF (25C): 50,000 h

• Backlight dimming: 10100%

Control Elements

• Numeric keyboard: Yes (onscreen)

• Alphanumeric keyboard: Yes (onscreen)

Touch Operation

• Touch screen: Yes

• Multi-touch: Yes

Installation

• Mounting position: Vertical

• Portrait orientation: Possible

• Landscape orientation: Possible

• Max tilt without external ventilation: 35

Supply Voltage

• Type: DC

• Rated value: 24 V

• Range: 19.2 28.8 V

Input Current

• Rated consumption: 1.2 A

• Max consumption: 1.7 A

• Inrush current: 0.5 As

Memory

• Flash: Yes

• RAM: Yes

Acoustics

• Buzzer: Yes

• Speaker: No

Clock

• Real-time clock: Yes

• Retentive: Yes (approx. 6 weeks backup)

• Synchronizable: Yes

Interfaces

• Industrial Ethernet: 2 (switch ports) + 1 independent

• RS485: 1 (RS422/485 combined)

• USB: 4 USB 3.1 Gen 1 (Type A)

• SD card slots: 2

Protocols

• PROFINET: Yes

• TCP/IP, DHCP, SNMP, DCP, LLDP: Supported

• MRP (media redundancy): Yes

EMC

• EN 55011 Class A: Yes

• Class B: No

Protection Classes

• Front: IP65, NEMA Type 4x / 12

• Rear: IP20

Approvals

CE, UKCA, cULus, RCM, KC, EAC, CCC.

Hazardous Areas

• ATEX Zone 2, 22: Yes

• IECEx Zone 2, 22: Yes

• cULus Class I/II Div 2: Yes

• FM Class I/II Div 2: Yes

Marine Approvals

ABS, BV, DNV, KRS, LRS, NK, CCS.

Ambient Conditions

• Indoor use: Yes

• Outdoor use: No

• Operating temperature (vertical): 0 to 45C

• Operating temperature (portrait): 0 to 40C

• Max tilt angle operation: 0 to 40C

• Storage/transport: -20 to 60C

• Humidity: Max 90% (no condensation)

Operating System & Functions

• Proprietary OS: Yes

• Alarms, message indicator, recipe management: Yes

• Configuration: WinCC Unified Comfort/PC Engineering

• Runtime languages: 32

• Project languages: 32

• JavaScript support: Yes

• Web browser: Yes

• Unified Collaboration: Yes

WinCC Unified Main Capabilities

• Bit messages: 9000

• Analog messages: 300

• Variables per device: 8000

• Images: 1200

• Objects per image: 1200

• Complex objects per image: 80

• Archives: 50

• Entries per archive: 500,000

• Backup/Restore: Manual & automatic

Process Coupling

• S7-1200 / S7-1500: Yes

• S7-300/400: Yes

• LOGO!: Yes

• OPC UA Client/Server: Yes

Peripherals

• Printer, barcode reader, SD memory card, USB sticks.

Mechanical Data

• Front material: Aluminum

• Front width: 464 mm

• Front height: 294 mm

• Cutout (W H): 448 278 mm

• Depth: 73 mm

• Weight: 5.5 kg
