SIMATIC S7-1500T, CPU 1515T-2 PN 6ES7515-2TN03-0AB0

About SIMATIC S7-1500T, CPU 1515T-2 PN 6ES7515-2TN03-0AB0

Manufacturer SeriesS7 1500Communication ProtocolsRS232Mounting Type Rack Mount Output Type plc Pulse Transmission Output Max. 4 (up to 100 kHz) SIMATIC S7-1500T, CPU 1515T-2 PN, central processing unit with 1.5 MB work memory for program and 4.5 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 6 ns bit performance, SIMATIC Memory Card required

Siemens SIMATIC S7-1500T CPU 1515T-2 PN

Part Number: 6ES7515-2TN03-0AB0

General Information

• Product type: CPU 1515T-2 PN

• HW functional status: FS05

• Firmware version: V4.0 (FW update possible)

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: Yes (Distributed & Central)

• SysLog: Yes

• Engineering with: STEP 7 TIA Portal (V20 for FW V4.0, V18 for FW V3.0 or higher)

• Configuration control: via dataset

• Display: 6.1 cm diagonal

• Control elements: 8 keys, 2 mode buttons

Power Supply

• Rated voltage: 24 V DC

• Permissible range: 19.2 28.8 V DC

• Reverse polarity protection: Yes

• Mains buffering: 5 ms

• Current consumption: 0.65 A (typ.), 1.03 A (max.)

• Inrush current: 1.15 A, It 0.6 As

• Power loss: 3.6 W (typ.)

• Backplane bus power: 12 W (infeed), 6.2 W (balanced)

Memory

• SIMATIC Memory Card: Required, 1 slot, up to 32 GB

• Work memory: 1.5 MB (program), 4.5 MB (data)

• Backup: Maintenance-free

• CPU processing times: Bit 6 ns, Word 7 ns, Fixed point 9 ns, Floating point 37 ns

CPU Blocks

• DB: 160,999 (user: 159,999; SFC 86: 60,00060,999), max 4.5 MB

• FB / FC: 065,535, max 1 MB each

• OB: Max 1 MB, various types and priorities

• Nesting depth: 24 per priority class

Timers & Counters

• S7 counters: 2,048 (retentive adjustable)

• IEC counters: Any (limited by memory)

• S7 timers: 2,048 (retentive adjustable)

• IEC timers: Any (limited by memory)

I/O

• Max I/O modules: 8,192

• Inputs/Outputs: 32 kB each (process image)

• Integrated subsystem: 8 kB each

• Subprocess images: Max 32

• Distributed I/O systems: Max 64

• DP/IO Controllers via CM/CP: Max 8

• Modules per rack: Max 32 (CPU + 31)

Clock / Timer

• Type: Hardware clock

• Backup time: 6 weeks (40C)

• Deviation: Max 10 s/day

• Operating hours counter: 16

• Clock synchronization: DP master/device, AS master/device, NTP on Ethernet

Interfaces

1st PROFINET interface (X1)

• RJ45, 2 ports, integrated switch

• IPv4, PROFINET IO Controller & Device, SIMATIC communication, Open IE (optional encryption), Web server

• IRT, Isochronous mode, PROFIenergy

• Max connectable IO Devices: 256 (64 with IRT)

2nd PROFINET interface (X2)

• RJ45, 1 port, no switch

• IPv4, PROFINET IO Controller & Device, Web server, Open IE

• Max connectable IO Devices: 32

• Ethernet: 100 Mbps, autonegotiation, autocrossing, Industrial Ethernet status LED

• Connections: Max 256

• MRP / MRPD support: Yes

• Redundancy: H-Sync forwarding

Communication Protocols

• S7 Communication: Server & client, routing, PG/OP

• Open IE: TCP/IP, UDP, ISO-on-TCP, DHCP, DNS, SNMP, DCP, LLDP, optional encryption

• OPC UA: Server & Client, Medium runtime license, max 10 client connections, 100,000 accessible variables

• Other protocols: MODBUS TCP

• Web server: HTTP/HTTPS, max 100 sessions, 4 simultaneous HTTP calls

Technology Objects

• Motion Control: Yes, 2,400 resources

• Positioning axes: 11 @ 4 ms cycle, 20 @ 8 ms cycle

• PID controllers: PID_Compact, PID_3Step, PID-Temp

• High-speed counters: Yes

Programming Languages

• LAD, FBD, STL, SCL, CFC, GRAPH

Security / Protection

• User program protection, copy/block protection

• Password for display, write/read protection

• Device-wide user administration: 100 users, 100 groups, 50 roles

Dimensions & Weight

• Width: 70 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: 456 g
