The SIMATIC S7 300 6ES7336 4GE00 0AB0 is a high-quality industrial automation module designed for seamless integration into standard DIN rail systems. With a sleek grey exterior, this product operates at a frequency of 50/60 Hertz (HZ) and comes with a reliable 1-year warranty. Its compact size makes it suitable for various industrial applications, ensuring efficient and robust performance in diverse settings.

SIMATIC S7 Analog Input SM 336 (6ES7336-4GE00-0AB0)

Type: Fail-safe Analog Input Module
Channels: 6 AI, 15-bit, HART support
Safety: Up to Category 4 (EN 954-1) / SIL3 (IEC 61508) / PLE (ISO 13849)
Connector: 1x 20-pin

Supply & Power

• Rated Supply Voltage: 24 V DC

• Reverse Polarity Protection: Yes

• Load Voltage L+: 24 V DC, reverse polarity protected

• Input Current:

  • From L+: typ. 150 mA

  • From backplane bus 5 V DC: max. 90 mA

• Power Loss: typ. 4.5 W

Analog Inputs

• Number of Inputs: 6

• Current Input Ranges:

  • 020 mA, 420 mA

  • Input resistance: typ. 150 , max. 175

• Voltage Inputs: Not supported

• Thermocouple/RTD/Resistance: Not supported

• Cable Length (shielded): max. 1,000 m

Signal Processing

• Resolution: 16-bit (15-bit + sign)

• Integration Time: 20 ms @ 50 Hz, 16.7 ms @ 60 Hz

• Interference Voltage Suppression: f = n (f1 0.5%)

• Encoder Support:

  • 2-wire and 4-wire transducers supported

Accuracy

• Operational Error (full temp. range): 0.2% / 40 A

• Basic Error (25 C): 0.1%

Diagnostics & Status

• Diagnostics Function: Yes

• Diagnostic Alarm: Yes

• LED Indications:

  • Fail-safe operation

  • Group error SF (red)

  • Encoder supply Vs (green) not available

Potential Separation & Isolation

• Between channels: Yes

• Channels Backplane Bus: Yes

• Channels Electronics Power Supply: Yes

• Isolation Test: 370 V for 1 min

Safety Standards

• EN 954: Category 4

• ISO 13849-1: Performance Level e

• IEC 61508: SIL 3

Mechanical Data

• Width: 40 mm

• Height: 125 mm

• Depth: 120 mm

• Weight: 350 g
