SIEMENS V90 SERVO MOTOR 1FL6067-1AC61-2AA1

About SIEMENS V90 SERVO MOTOR 1FL6067-1AC61-2AA1

Power2 KWVoltage400SIMOTICS S-1FL6-1FL6 Operating voltage 3AC 400 V Pn=2 kW; Nn=2000 rpm M0=15 Nm; MN=9.55 Nm Shaft height 65 mm, with angle plug; incremental encoder 2500 incr./rev. with feather key, tolerance N without holding brake Degree of protection IP65 with sealing ring compatible with the converters SINAMICS V70 & V90

Engineering Data

• Rated speed: 2,000 rpm

• Rated torque (100 K): 9.55 Nm

• Rated current: 5.9 A

• Rated power: 2.00 kW / 2.72 hp

• Max. speed: 3,000 rpm

• Maximum torque: 28.70 Nm

• Max. current: 17.7 A

• Static torque: 15.00 Nm

• Moment of inertia: 29.900 kgcm

Physical Constants

• Torque constant: 1.70 Nm/A

• Thermal class: B (130 C)

• Net weight: 13.70 kg

Ambient Conditions

• Ambient temperature (operation): 0 40 C

• Relative humidity (max. operation): 90% RH (no condensation at 30 C)

Standards

• Compliance with standards: CE, EAC

Mechanical Data

• Motor type: High Inertia

• Motor type: Permanent-magnet synchronous motor

• Shaft height: 65

• Encoder system: Incremental encoder TTL, 2500 S/R (13 bit)

• Cooling: Natural cooling

• Shaft end: Feather key

• Radial runout tolerance: Class N

• Vibration severity grade: Grade A

• Degree of protection: IP65

• Design acc. to Code I: IM B5 (IM V1, IM V3)

• Connection type: Angular connector (rotatable)
