SIEMENS V90 SERVO MOTOR 1FL6092-1AC61-2AA1

About SIEMENS V90 SERVO MOTOR 1FL6092-1AC61-2AA1

SIMOTICS S-1FL6-1FL6 Operating voltage 3AC 400 V PN=3.5 kW; NN=2000 rpm, M0=22 Nm; MN=16.7 Nm Shaft height 90 mm, with angle connector; Incremental encoder 2500 incr./rev. with feather key, tolerance N without holding brake degree of protection IP65 with sealing ring compatible with the converters SINAMICS V70&V90

Data Sheet SIMOTICS S-1FL6

Article No.: 1FL6092-1AC61-2AA1

Engineering Data

• Rated speed: 2,000 rpm

• Rated torque (100 K): 16.70 Nm

• Rated current: 11.0 A

• Rated power: 3.50 kW / 4.76 hp

• Max. speed: 3,000 rpm

• Maximum torque: 50.00 Nm

• Max. current: 32.9 A

• Static torque: 22.00 Nm

• Moment of inertia: 69.100 kgcm

Physical Constants

• Torque constant: 1.60 Nm/A

• Thermal class: B (130 C)

• Net weight: 19.80 kg

Ambient Conditions

• Operating temperature: 0 40 C

• Relative humidity:

  • Up to 90% RH, non-condensing at 30 C

Standards

• Compliance: CE, EAC

Mechanical Data

• Motor type: High-Inertia PMSM (Permanent-Magnet Synchronous Motor)

• Shaft height: 90

• Encoder system: Incremental encoder, TTL, 2500 S/R (13-bit)

• Cooling: Natural cooling

• Shaft end: Feather key

• Radial runout tolerance: Class N

• Vibration severity grade: A

• Degree of protection: IP65

• Design (mounting): IM B5 (also IM V1, IM V3)

• Connection type: Angular connector (rotatable)
