About SIEMENS V90 SERVO MOTOR 1FL6096-1AC61-2AA1

SIMOTICS S-1FL6-1FL6 Operating voltage 3AC 400 V Pn=7 kW; Nn=2000 rpm M0=40 Nm; MN=33.4 Nm Shaft height 90 mm, with angle plug; incremental encoder 2500 incr./rev. with feather key, tolerance N without holding brake Degree of protection IP65 with sealing ring SINAMICS V70 & V90

SIMOTICS S-1FL6

Article No.: 1FL6096-1AC61-2AA1

Engineering Data

• Rated Speed: 2,000 rpm

• Rated Torque (100 K): 33.40 Nm

• Rated Current: 13.2 A

• Rated Power: 7.00 kW / 9.52 hp

• Max. Speed: 2,000 rpm

• Max. Torque: 90.00 Nm

• Max. Current: 35.6 A

• Static Torque: 40.00 Nm

• Moment of Inertia: 134.3 kgcm

Physical Constants

• Torque Constant: 2.70 Nm/A

• Thermal Class: B (130 C)

• Net Weight: 33.30 kg

Ambient Conditions

• Operating Temperature: 0 40 C

• Relative Humidity: Max. 90% RH (no condensation at 30 C)

Standards

• Compliance: CE, EAC

Mechanical Data

• Motor Type: High Inertia, Permanent-Magnet Synchronous Motor

• Shaft Height: 90 mm

• Encoder System: Incremental TTL, 2500 S/R (13 bit)

• Cooling: Natural Cooling

• Shaft End: Feather Key

• Radial Runout Tolerance: Class N

• Vibration Severity Grade: Grade A

• Degree of Protection: IP65

• Design: Code I IM B5 (IM V1, IM V3)

• Connection Type: Angular Connector (rotatable)
