SIEMENS 6ES7131 S7-ET200SP 16 Digital Input 6ES7131-6BH01-0BA0

About SIEMENS 6ES7131 S7-ET200SP 16 Digital Input 6ES7131-6BH01-0BA0

General Information

• Product Type: DI 16x24VDC ST

• Hardware Status: From FS02

• Firmware Version: V0.0 (No firmware update possible)

• Usable BaseUnit: BU type A0

• Color Code: CC00

• I&M Data: Yes (I&M0 to I&M3)

• Isochronous Mode: No

• PROFINET R1 Support: Yes

Engineering Software Compatibility

• TIA Portal: V14 or higher

• STEP 7: V5.5 SP3

• PCS 7: V8.1 SP1

• PCS neo: From V1.0.0

• PROFIBUS GSD: Revision 3 & 5+

• PROFINET GSDML: V2.3

Operating Modes

• Digital Input: Yes

• Counter: No

• Oversampling: No

• MSI: No

Supply Voltage

• Rated: 24 V DC

• Range: 19.2 28.8 V DC

• Reverse Polarity Protection: Yes

Current & Power

• Max Current Consumption: 90 mA

• Power Loss: 1.7 W

Address Area

• Inputs: 2 bytes

• Additional QI Information: 2 bytes

Hardware Configuration

• Automatic Encoding: Yes

• Mechanical Coding: Type A

Supported BaseUnit Connection Types

• 1-wire: BU type A0

• 2-wire: BU type A0 + Potential Distributor

• 3-wire: BU type A0 + Potential Distributor

• 4-wire: BU type A0 + Potential Distributor

Digital Inputs

• Number of Inputs: 16

• Parameterizable: Yes

• Type: P-reading (sink input, PNP)

• IEC 61131 Type 3: Yes

Input Voltage

• Rated: 24 V DC

• Signal "0": 30 to +5 V

• Signal "1": +11 to +30 V

Input Current

• Signal "1": ~2.5 mA

Input Delay

Parameterizable (standard inputs):
0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms
(+ additional 30500 s depending on cable length)

• 0 1: 0.05 to 20 ms

• 1 0: 0.05 to 20 ms

Cable Length

• Shielded: max. 1000 m

• Unshielded: max. 600 m

Encoder Support

• Compatible with 2-wire sensors

• Max quiescent current: 1.5 mA

Diagnostics & Alarms

• Diagnostics Available: Yes

• Diagnostic Alarm: Yes

• Supply Voltage Monitoring: Yes (parameterizable)

• Encoder Supply Monitoring: No

• Wire-break Detection: Yes (module-wise)

  • Optional protective resistor: 25 k 45 k

• Short-circuit: No

• Group Error: Yes

LED Indicators

• Supply Monitoring: Green PWR LED

• Channel Status: Green LED

• Module Diagnostics: Green/Red DIAG LED

• Channel Diagnostics: No

Isolation & Protection

• Between Channels: No

• Channels Backplane Bus: Yes

• Channels Electronics Power: No

• Isolation Test Voltage: 707 V DC

• Suitable for Safety Functions: No

Environmental Data

• Environmental Product Declaration: Yes

Global Warming Potential

• Total: 21 kg CO eq

• Production: 4.25 kg

• Operation: 17.5 kg

• End of Life: 0.743 kg

Ambient Conditions

• Temperature (Horizontal): 30 to +60 C

• Temperature (Vertical): 30 to +50 C

• Installation Altitude: Up to 5000 m
  (Restrictions > 2000 m see manual)

Mechanical Data

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: ~28 g
