About SIEMENS V90 SERVO DRIVE 6SL3210-5FE13-5UA0

SINAMICS V90

Article No.: 6SL3210-5FE13-5UA0

Technical Note: Data subject to change. Values may differ from rating plate.

Rated Data

Input:

• Phases: 3 AC

• Line voltage: 380 480 V (+10% / -15%)

• Line frequency: 45 66 Hz

Output:

• Rated power: 3.5 kW

• Rated current (IN): 11 A

• Maximum output current: 33 A

Inputs / Outputs

• Standard digital inputs: 10

• Digital outputs: 6

• Analog inputs: 2

• Analog outputs: 2

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSC

• Net weight: 5.65 kg

• Dimensions: W 140 H 260 D 240 mm

Ambient Conditions

• Cooling: Fan

• Installation altitude: 1,000 m

• Operation temperature: 0 45 C

• Storage temperature: -40 70 C

• Relative humidity: Max 90%
