About SIEMENS VFD G120XA 6SL3220-2YD14-0CB0

SINAMICS G120XA Datasheet

Article No.: 6SL3220-2YD14-0CB0
Technical data may change. Calculated and rating plate values may differ.

General Information

• Phases (Input / Output): 3 AC

• Line Voltage: 380 440 V (+10% / -20%)

• Line Frequency: 47 63 Hz

• Rated Current (LO): 3.60 A

Output Data

• Rated Voltage: 400 V

• Rated Power (IEC 400V, LO): 1.50 kW

• Rated Current (400 V / 380 V / LO): 4.10 A

• Max. Output Current: 4.50 A

• Pulse Frequency: 4 kHz

• Output Frequency (Vector Control): 0 240 Hz

• Output Frequency (V/f Control): 0 550 Hz

Overload Capability

• Low Overload (LO):

  • 110% of base load current (IL) for 60 s in 600 s cycle

• Max Output Current (60 s / 600 s cycle): 4.50 A

General Technical Specifications

• Power Factor (): 0.75 0.93

• Cos 1: 0.99

• Efficiency (): 0.97

• Noise Level (1 m): 55 dB

• Power Loss: 0.072 kW

• Filter Class: RFI Category C3

• EMC Category (with accessories): C3

• Safety Function: STO (Safe Torque Off)

Communication Interfaces

• Protocols: USS, Modbus RTU, BACnet MS/TP

Inputs / Outputs

Digital Inputs

• Quantity: 6

• Switching Level 0 1: 11 V

• Switching Level 1 0: 5 V

• Max Inrush Current: 15 mA

Fail-Safe Digital Inputs

• Quantity: 0

Digital Outputs

• Relay Output: 4 (changeover)

• Resistive Load: 30 V DC / 1.0 A

• Transistor Outputs: 0

Analog / Digital Inputs

• Quantity: 2 (differential)

• Resolution: 12 bit

• Digital Threshold 0 1: 4 V

• Digital Threshold 1 0: 1.6 V

Analog Outputs

• Quantity: 2 (non-isolated)

PTC / KTY Motor Temperature

• Supports PTC, KTY, PT1000, Thermo-Click

• Accuracy: 5 C

Control Functions

• V/f control (linear / square-law / parameterizable)

• V/f ECO mode

• FCC (Flux Current Control)

• Sensorless vector control

• Encoderless torque control

• No encoder-based vector control

Ambient Conditions

• Board Coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air (integrated fan)

• Air Requirement: 0.005 m/s

• Altitude: 0 1000 m

• Operating Temperature: -20 60 C

• Storage/Transport: -40 70 C

• Max Humidity: 95% (no condensation/icing)

Connections

Signal Cable

• Conductor Size: 0.15 1.50 mm (AWG 2416)

Line Side

• Connection: Screw terminal

• Wire Size: 1.50 2.50 mm (AWG 1614)

Motor End

• Connection: Screw terminal

• Wire Size: 1.50 2.50 mm (AWG 1614)

DC Link / Braking Resistor

• PE Connection: M4 screw

Max Motor Cable Length

• Shielded: 50 m

Mechanical Data

• Protection Class: IP20 / UL Open Type

• Frame Size: FSA

• Weight: 3.4 kg

• Dimensions (W H D): 73 232 209 mm

Standards & Certifications

• Compliance: CE, EAC, RCM, RoHS II

• Directives:

  • EMC: 2004/108/EC

  • Low Voltage: 2006/95/EC

• Efficiency Class: IE2

Operator Panel BOP-2

Display

• Type: LCD, monochrome

Mechanical

• Protection: IP55 / UL Type 12

• Weight: 0.140 kg

• Dimensions: 70 106.85 19.60 mm

Ambient Conditions

• Operation Temp: 0 50 C

• Storage/Transport: -40 70 C

• Humidity: 95%

Technical Details
