SIEMENS CPU1515SP PC2 (6ES7677-2DB42-0GB0)

The SIEMENS CPU1515SP PC2 is a robust and reliable automation controller designed for demanding industrial applications.

Key Specifications:

• Processor: Intel Atom E3940, 4 cores, 1.6 GHz

• Operating System: Windows 10

• Rated Voltage: 24V DC

• Input Current: 2.9 A

• Power Rating: 43 W

• Dimensions (L W H): 160 117 75 mm

• Weight: 0.83 kg

• Operating Temperature: -20C to +60C

• Humidity Tolerance: Up to 95%

• Protection Level: IP20

• Mounting: DIN rail

Features:

• Compact and lightweight for space-constrained installations

• High-speed performance for seamless industrial automation

• Durable and reliable under varied environmental conditions

• Easy DIN-rail installation for convenient setup

The CPU1515SP PC2 offers advanced features to optimize industrial operations efficiently and reliably.

SIMATIC ET 200SP Open Controller CPU 1515SP PC2

• Product Code: 6ES7677-2DB42-0GB0
• Basic Device: 6ES7677-2DB40-0AA0
• OS: Windows 10 IoT Enterprise LTSC 2019, 64-bit
• Preinstalled Software: S7-1500 Software Controller CPU 1505SP V2x

General Information

• HW Status: FS04

• Firmware Version: V20.8

• Engineering: STEP 7 TIA Portal V16 or higher

• Mode Selector Switch: 1

• CFast Slot: 1 (128 GB)

• SD/MMC Slot: 1

• ET 200SP BusAdapter Connection: 1

• Ethernet: 1x 10/100/1000 Mbps

• USB: 2x USB 3.0, 2x USB 2.0

• DisplayPort: 1

• Documentation: On CFast with restore image

Power Supply

• Rated Voltage: 24 V DC

• Permissible Range: 19.2 28.8 V DC

• Reverse Polarity Protection: Yes

• Mains Buffering: 5 ms

• Current Consumption:

  • Rated: 1.8 A (full load)

  • Typ.: 0.5 A (no load)

  • Max: 2.9 A

• Power Loss: Typ. 16 W

• Active Power Input Max: 43 W

Processor

• Type: Intel Atom E3940, 1.6 GHz, 4 cores

• Memory: DDR3L, 8 GB RAM

• CFast Memory: 128 GB

• Work Memory:

  • Program: 1 MB

  • Data: 5 MB

  • CPU Function Library: 20 MB

• Load Memory: 320 MB

• UPS/Backup: Yes (all memory areas retentive)

CPU Blocks

• Total Elements: 6,000

• DB: Max 5,999, Size up to 5 MB

• FB: Max 5,998, Size up to 1,024 kB

• FC: Max 5,999, Size up to 1,024 kB

• OB: Size up to 1,024 kB; multiple types for alarms, interrupts, startup, errors

Counters & Timers

• S7 Counters: 2,048 (retentive adjustable)

• IEC Counters: Any (limited by memory)

• S7 Timers: 2,048 (retentive adjustable)

• IEC Timers: Any (limited by memory)

Data & Address Areas

• Retentive Data: 410 kB (NVRAM), 5.24 MB (mass storage)

• Flags: 16 kB, 8 clock memories

• Local Data: 64 kB per priority class

• I/O Address Area: Inputs 32 kB, Outputs 32 kB

• Number of I/O Modules: 8,192

• Subprocess Images: Max 32

Hardware & Interfaces

• Integrated Power Supply: Yes

• Distributed I/O Systems: 20

• DP Masters: 1 (via CM)

• IO Controllers: 1 (via PC interfaces)

• Max ET 200SP Modules: 64

• Max ET 200AL Modules: 16

• Industrial Ethernet Interfaces: 2

• PROFINET Interfaces: 1

• PROFIBUS Interfaces: 1

• RS 485 Interfaces: 1 (via CM DP module)

• USB Interfaces: 4 (2x USB 2.0, 2x USB 3.0)

• SD Card Slot: 1

• Display Port: 1

Protocols & Services

• PROFINET IO Controller: IRT, Isochronous mode, PROFIenergy, max 128 IO Devices

• PROFINET IO Device: IRT, Isochronous mode, Shared device

• Ethernet: 1x 1000 Mbps, Autonegotiation, RJ45

• PROFIBUS DP Master/Device: Max 125 DP devices

• RS 485: Max 12 Mbit/s

• Redundancy: MRP, MRPD, Switchover 200 ms, Max stations 50

• SIMATIC Communication: PG/OP, S7 Routing, S7 Server/Client, Max 64 kB user data

• Open IE Communication: TCP/IP, ISO-on-TCP, UDP, SNMP, DCP, LLDP

• Web Server: HTTP/HTTPS via Windows & PROFINET

• OPC UA: Client & Server (runtime license required)

• MODBUS TCP: Supported

Programming & Diagnostics

• Programming Languages: LAD, FBD, STL, SCL, GRAPH (No CFC)

• Forcing: Yes, Max 200 variables

• Traces: 4, 512 kB per trace

• Motion Control: 2,400 resources, max 30 positioning axes

• PID Controllers: PID_Compact, PID_3Step, PID_Temp

• High-Speed Counter: Yes

• Alarms: Program max 1,000, System 200, Motion 160

Standards & Certifications

• CE Mark, CSA, cULus, FM, RCM

Ambient Conditions

• Operating Temperature: -20 C to 60 C (depends on ET 200SP modules)

• Storage Temperature: -40 C to 70 C

• Vibrations & Shock: IEC 60068-2 tested

Dimensions & Weight

• Width: 160 mm

• Height: 117 mm

• Depth: 75 mm

• Weight: 0.83 kg
